1.2 / industry-best video processing technologies with High Dynamic Range (HDR) picture refinement.
- LED HDR picture refinement technology
- Detailed, true-to-life color presentation
- Convenient installation and operation
Bright and Clear LED Expression
The IF Series’ integrated HDR adaptation optimizes gradation within individual scenes for a consistent, shine-free presentation. For added detail and quality, the displays’ complementary dynamic peaking elevates peak brightness to levels nearly two times higher than the standard LED maximum.
Accurate Color in Low Brightness Arenas
Conventional LED displays struggle to present red, green and blue color hues accurately in low grayscale settings. The IF Series overcomes these challenges through a unique algorithm that maintains R/G/B gradation and delivers precise, detail-rich hues in low-brightness indoor environments.
|Physical Parameter data|
|Pixel Pitch||1.26 mm|
|Pixel Configuration||1 red, 1 green, 1 blue|
|Configuration (LxH, per cabinet)||640x360 pixels|
|Diode Type||Surface Mount Device (SMD)|
|Dimensions (㎜, LxHxD, per cabinet)||806.4x453.6x76.7mm|
|Dimensions (inch, inchxD, per cabinet)||36.4 inch x 3.02 inch|
|Weight (per cabinet/per ㎡)||11.8Kg / 32.3Kg|
|Optical Parameter data|
|Contrast Ratio (Peak/Max)(1)||8,000:1 / 4,000:1|
|Viewing angle - Horizontal||160°|
|Viewing angle - Vertical||160°|
|Bit Depth||16bit per Color|
|Color Temperature - Default||6,500K|
|Color temperature - Adjustable||2,800 ~ 10,000K (use S/BOX)|
|Video Rate||50/60 Hz|
|Cabinet - Input Power Range||100~240 VAC, 50/60 Hz|
|Power consumption - Max||711 (W/㎡) / 260 (W/Cabinet)|
|Power consumption - Typical||237 (W/㎡) / 87 (W/Cabinet)|
|Heat Generation - Max(BTU/SF)||225 BTU/SF per hour|
|Refresh rate||3,840 Hz|
|Operation Conditions data|
|Working Temperature / Humidity||0°C~40°C / 10~80%RH|
|Storage Temperature / Humidity||-20°C~45°C / 5~95%RH|
|LED Lifetime||100,000 hours to half brightness|
|Certification||EMC Class B, Safety 60950-1|
|Service||Front(3) and Parts Rear(4)|
|Box Dimension (WxDxH)||943 x 606 x 167|
|Box Volume (m3)||0.095|
|Package Weight (kg, per cabinet)||16.5kg|
|Disclaimer(1)||Peak Value according to IDMS (Information Display Measurement Standard)|
|Disclaimer(3)||Front Service : IFJ and IF-D offer Front Service to Power Supply/Main Board on a cabinet level|
|Disclaimer(4)||Parts Rear Service : IFJ and IF-D's Power Supply/Main Board can be accessed from the rear|
