RGB Spectrum SuperView 4K – 4K UHD Multiviewer

Product Overview

The RGB Spectrum SuperView 4K is an 8-megapixel 4K multiviewer engineered for control rooms, command centers, and high-resolution monitoring environments where multiple live sources must appear on a single 4K display. Paired with a 4K monitor or projector, this multi-image processor delivers a multi-window video output with the clarity AV integrators expect from a commercial-grade 4K UHD multiviewer. Built on RGB Spectrum's real-time, embedded architecture, it processes images with no dropped frames and supports HDCP for protected content. It is a strong fit for integrators specifying a DVI and HDMI multiviewer for government, security, and enterprise control-room deployments.

Product Description

The SuperView 4K accepts up to eight DVI or HDMI inputs and, when 4K content is displayed, arranges up to four HD (1920x1080) windows on screen; with HD content alone, up to eight windows are available. Any HD window can be shown at full resolution without downscaling, so source detail is preserved across every layout. The processor drives four single-link DVI outputs (or two dual-link outputs) and accommodates 4K signals at 3840x2160 and 4096x2160, making it well suited to large-format control-room walls and high-pixel-count displays.

Creative features include dynamic window sizing and positioning, panning and zooming within images, custom borders, titles, and programmable display layouts, giving operators full command of how sources are presented. The unit installs in a standard 2RU rack space and is controlled over Ethernet via Telnet, a built-in web interface, or RS-232, simplifying integration into an existing control system. For teams comparing options, this model sits alongside other RGB Spectrum multiviewers and video distribution products at Creation Networks. To scope a full command-center deployment, review our command and control AV solutions. Built for 24/7 operation, the SuperView 4K is engineered for the reliability demanded by always-on monitoring rooms.

Key Features

• 8-Megapixel 4K Output — Combined with a 4K display, the processor produces a true 8-million-pixel multi-image canvas for high-detail monitoring.
• Eight DVI/HDMI Inputs — Accepts up to eight DVI-I or HDMI 1.3a sources, covering a wide range of computer and video signals in one chassis.
• Full-Resolution HD Windows — Any HD window can be displayed at native 1920x1080 without downscaling, preserving source clarity.
• Flexible Output Modes — Drives four single-link DVI outputs, or two dual-link outputs, and accommodates 4K signals at 3840x2160 and 4096x2160.
• Dynamic Window Scaling — Windows can be sized and positioned anywhere on screen, with pan-and-zoom within any image.
• Programmable Layouts — Operators can store and recall display layouts, with custom borders and titles for clear source identification.
• HDCP Support — Single-link output mode is HDCP compliant for displaying protected content.
• Embedded Real-Time Architecture — Hardware-based processing delivers smooth output with no dropped frames for 24/7 operation.

Typical Applications

• Command and control centers — Security operations centers, emergency operations centers, and 24/7 monitoring rooms that consolidate many sources onto one 4K display.
• Government and defense spaces — Secure monitoring environments requiring high-resolution multi-source visualization.
• Broadcast studios — Multi-source confidence monitoring and signal review on a single large-format screen.
• Training rooms and auditoriums — Presenting multiple high-resolution sources side by side for instruction and briefings.

Technical Specifications

Source: RGB Spectrum.

Frequently Asked Questions

What sources and displays is the SuperView 4K compatible with?
It accepts up to eight DVI-I, DVI, or HDMI 1.3a inputs spanning resolutions from 640x480 to 1080p, plus 4K signals via single-link DVI channels. Outputs drive DVI single-link or dual-link displays, and 4K monitors or projectors when configured for 4K output.

How is it installed and mounted?
The unit occupies a standard 2RU rack space and weighs 25 lbs. It runs on 100-240 VAC auto-ranging power and supports DVI cable runs up to 164 ft (50 m) with automatic or manual equalization.

How does it integrate into an existing AV or control system?
Control is available over Ethernet (10/100Base-T) via Telnet or the built-in web interface, as well as RS-232 for third-party control systems, so it drops into most command-center and control-room workflows.

Does it support HDCP-protected content?
Yes. In single-link output mode the SuperView 4K is HDCP compliant; note that dual-link output mode is non-compliant.

What warranty and support are available?
This is a commercial RGB Spectrum product backed by manufacturer support. For warranty details, configuration help, or a project quote, contact Creation Networks at 888-230-3661 or via our contact page.
