Renkus-Heinz TX61 2-Way Loudspeaker 6.5" LF, 1" HF, non-powered
Renkus-Heinz TX61 2-Way Loudspeaker 6.5" LF, 1" HF, non-powered - Black is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Renkus-Heinz TX61 2-Way Loudspeaker 6.5" LF, 1" HF, non-p...
Product Overview
The Renkus-Heinz TX61 is a compact, externally powered 6.5-inch two-way point-source loudspeaker, built to order for permanent commercial installations needing discreet, wide coverage. It combines a 6.5-inch heavy-duty woofer and a 1-inch titanium HF driver on a wide-angle Complex Conic waveguide, with a built-in passive crossover. As an install loudspeaker, it suits fills, delays, and distributed playback in huddle rooms, conference rooms, and house-of-worship spaces.
Product Description
Every T Series loudspeaker is built to order in the Renkus-Heinz California factory to exacting standards of performance and durability. The TX61 features a 6.5-inch heavy-duty woofer and a 1-inch Extended Range titanium HF driver, with a wide 150° x 60° Complex Conic horn for broad, even coverage from a very compact enclosure. Connections are made through screw terminals and looping 4-pin Neutrik Speakon-style connectors. The TX61 can be field-upgraded to a self-powered TA61 using a Renkus-Heinz SA625 amplifier module. The small cabinet mounts discreetly for fill, delay, and playback duties in space-constrained rooms.
Key Features
- Compact 6.5-Inch Two-Way — A 6.5-inch woofer and 1-inch titanium HF driver deliver full-range ± 3 dB output from 100 Hz to 18 kHz in a small enclosure.
- Wide 150° x 60° Coverage — The rotatable Complex Conic horn provides smooth, wide-angle pattern control with low distortion.
- High-Volume Output, Small Footprint — The cabinet delivers strong output where size is a critical constraint.
- Field-Upgradeable to Powered — The cabinet can be converted to a self-powered TA61 with a Renkus-Heinz SA625 amplifier module.
- Standard Speakon Connectivity — Screw terminals and looping Neutrik Speakon-style connectors simplify passive system wiring.
- Discreet Installation — The compact cabinet is ideal for fills, delays, and distributed playback where size is critical.
Typical Applications
- Huddle room
- Conference room
- Boardroom
- House of worship
- Commercial meeting space
Technical Specifications
| LF Driver | SSL6.5-18, 6.5 in., 100 W AES @ 16 ohms |
| HF Driver | SSD1445-16, 1 in. titanium, 20 W AES |
| Sensitivity | 94 dB (1 W / 1 m) |
| Frequency Response | ± 3 dB, 100 Hz to 18 kHz |
| Dispersion | 150° H x 60° V, rotatable |
| Maximum SPL | 120 dB peak |
| Power Handling | 100 W AES / 200 W program @ 16 ohms |
| Connectors | Screw terminals & looping 4-pin Neutrik Speakon-style |
| Enclosure | 15 mm Lite Ply, perforated metal grille |
| Mounting | 12-point Universal Mounting Hardware (M6); M10 U-bracket points |
| Dimensions | 16 in. H x 7-7/8 in. W x 9-3/8 in. D (406 x 200 x 238 mm) |
| Weight | 20 lbs / 9 kg |
Frequently Asked Questions
Is the TX61 powered? No. It is an externally powered (passive) loudspeaker requiring an external amplifier. For a self-powered version, choose the TA61 with an integrated SA625 amplifier module.
What coverage does it provide? The Complex Conic horn delivers wide 150° x 60° coverage, well suited to fill and distributed applications.
Where is it typically used? Its compact size makes it ideal for fills, delays, and distributed playback in space-constrained rooms.
Can it be paired with a subwoofer? Yes. It integrates well with Renkus-Heinz T and S Series subwoofers. See the Renkus-Heinz collection.
What warranty applies? Warranty terms vary by product and region. Contact Creation Networks for current warranty and support details.
