Sound Control Technologies RTK-X57-PSU – Conference Table Extension Kit for Poly Studio Video Bar

Product Overview

The Sound Control Technologies RTK-X57-PSU RemoteTableKit is a conference table extension kit built exclusively for the Poly Studio, Studio X52, Studio X50, and Studio X70 Video Bar. Like the RTK-X57, it delivers power, video, audio, control, USB, and Ethernet over a single CAT cable from the conference table to the codec rack. The RTK-X57-PSU variant includes a dedicated external power supply unit (PSU) configuration for installations where the codec's internal power delivery requires supplemental power sourcing.

Product Description

The RTK-X57-PSU provides the same complete signal extension capabilities as the RTK-X57 — carrying power, video, audio, RS-232 control, USB, and Ethernet over a single CAT cable — while accommodating Poly Studio Video Bar installations that require an external PSU configuration. This makes it appropriate for deployment scenarios where the codec's internal power budget or physical installation constraints require the table transmitter to draw power from a separate supply rather than solely from the codec end.

BYOM functionality is supported through Poly Device Mode: when the codec is in Device Mode, the table unit presents a USB-C connection for laptop-based BYOM users. PoE for Poly TC8 and TC10 touch panels is delivered from the table transmitter. The Poly Expansion Mic is supported. No programming or configuration is required. MSRP: $2,925. Country of origin: USA/Taiwan.

Key Features

• PSU-Configuration Variant — Designed for Poly Studio Video Bar installations requiring an external power supply at the transmitter end, differentiating it from the standard RTK-X57.
• Single CAT Cable Infrastructure — All signals (power, video, audio, USB, Ethernet, control) run over one CAT cable between the table TX and the codec-end RX module.
• BYOM Support via Poly Device Mode — Provides USB-C table connectivity for laptop-based BYOM users when the Poly codec is placed in Device Mode.
• PoE for Touch Panels — Delivers PoE to Poly TC8 and TC10 touch panels directly from the table transmitter.
• Poly Expansion Mic Compatible — Supports the Poly Expansion Mic for additional microphone coverage.
• No Configuration Required — Plug-in compatible with supported Poly Video Bar codecs; no programming or scripting needed.

Typical Applications

• Conference room with Poly Studio Video Bar requiring PSU-configuration table extension
• Boardroom BYOM installation with Poly Device Mode workflow
• Commercial meeting space with Poly TC8/TC10 touch panel control
• Multi-purpose room supporting both traditional conferencing and BYOM

Technical Specifications

Frequently Asked Questions

What is the difference between the RTK-X57 and RTK-X57-PSU?

Both models extend the same signals over a single CAT cable for Poly Studio X-series codecs. The RTK-X57-PSU includes an external power supply unit (PSU) configuration for installations where supplemental power is required at the transmitter end. Contact Creation Networks to determine which variant is appropriate for your specific installation.

Does the RTK-X57-PSU support BYOM?

Yes. When the Poly codec is placed into Poly Device Mode, the RTK-X57-PSU provides a USB-C connection at the table for laptop-based BYOM users, giving them control of the room's display, camera, and audio without additional adapters.

What touch panels are supported?

The RTK-X57-PSU delivers PoE to Poly TC8 and TC10 touch panels from the table transmitter unit.

Are replacement modules available for the RTK-X57-PSU?

The RTK-X57-RX and RTK-X57-TX modules are compatible with RTK-X57-PSU installations. Contact Creation Networks to confirm module compatibility for your specific deployment.

What warranty applies?

Contact Creation Networks for current Sound Control Technologies warranty terms for the RTK-X57-PSU.
