Sound Control Technologies RCS-PH1 – Sheetrock Ceiling Mount for Cisco PrecisionHD 12x/4x

Product Overview

The Sound Control Technologies RCS-PH1 is a ceiling mount for Cisco PrecisionHD 12x and 4x 1080p cameras in sheetrock (drywall) ceiling applications, recessing the camera into the ceiling plane for a clean, low-profile installation. As part of the SCT RCS Series of sheetrock ceiling mounts, it combines a recessed backbox, mounting plate, and a camera cradle matched to the PrecisionHD body. It serves installed-base Cisco rooms where a ceiling camera position is required without visible poles or exposed hardware.

Product Description

Cisco PrecisionHD 12x and 4x cameras remain in service across SX and C-series room systems, and ceiling positions are often the only way to capture deep rooms or instructor positions. The RCS-PH1 recesses the camera into the drywall ceiling: the backbox installs above the ceiling line, the mounting plate trims the opening, and the cradle secures the inverted PrecisionHD camera with cabling terminated inside the enclosure. Nothing is exposed in the room except the camera itself, sitting neatly within the ceiling plane. The mount pairs with SCT camera extension kits, which carry video, control, and power over a single CAT cable through the plenum to a remote equipment rack. Per the RCS Series design, the mount is specific to sheetrock construction; for T-bar tile ceilings, the SCT RCT-PH1 serves the same camera. Note this is a legacy RCS Series model matched to the PrecisionHD generation; for current round-base PTZ cameras, specify the RCS-UNI in the same series.

Key Features

• Cisco PrecisionHD Specific — The cradle is matched to the PrecisionHD 12x and 4x 1080p camera bodies for a secure, aligned seat.
• Sheetrock Ceiling Design — The recessed backbox and mounting plate install in drywall ceiling construction.
• Recessed, Low-Profile Appearance — The camera sits within the ceiling plane with no visible pole or surface box.
• Concealed Cable Management — Video, control, and power cabling terminate inside the backbox above the ceiling.
• Extension-Kit Friendly — Works with SCT camera extension kits for single-CAT-cable runs through the plenum to the rack.
• Installed-Base Support — Lets Cisco SX and C-series rooms gain ceiling camera coverage without replacing cameras.

Typical Applications

• Conference rooms and boardrooms with installed Cisco PrecisionHD cameras
• Training rooms and lecture spaces needing instructor or audience capture from the ceiling
• Government spaces standardized on Cisco video infrastructure
• Auditoriums and multi-purpose rooms with finished drywall ceilings

Technical Specifications

Frequently Asked Questions

Which cameras does the RCS-PH1 support?
The Cisco PrecisionHD 12x and 4x 1080p cameras used with Cisco SX and C-series codecs.

Does it work in suspended tile ceilings?
No. The RCS Series is for sheetrock (drywall) ceilings; specify the SCT RCT-PH1 for T-bar tile ceiling installations of the same camera.

Is this model still current?
The RCS-PH1 is a legacy RCS Series model matched to the PrecisionHD generation. Contact our sales team to confirm availability; for current round-base PTZ cameras the RCS-UNI is the standard model.

Can cabling run back to a remote rack?
Yes. Pair the mount with an SCT camera extension kit to carry video, control, and power over a single CAT cable through the plenum to the equipment rack.

How do I get a quote?
Use the Contact Sales option on this page and Creation Networks will confirm configuration, availability, and lead time.
