Sound Control Technologies RCR-UNI – Recessed Wall Mount for Round-Base PTZ Cameras

Product Overview

The Sound Control Technologies RCR-UNI is a universal recessed wall mount for round-base PTZ cameras, recessing the camera into the wall for a flush, finished look in conference rooms and boardrooms. Part of the SCT RCR Series of in-wall camera mounts, it combines a wall backbox with a customizable base shelf that matches the contoured base of standard round-base PTZ cameras. It is the broadest-compatibility model in the series, covering popular video conferencing and broadcast PTZ cameras from Sony, Panasonic, Lumens, AVer, PTZOptics, QSC, Marshall, Logitech, HP Poly, and Cisco.

Product Description

Wall-protruding camera brackets disrupt room aesthetics and are vulnerable in busy commercial meeting spaces. The RCR-UNI recesses a round-base PTZ camera into the wall cavity: the backbox installs between studs, cabling terminates inside the enclosure, and the camera sits on a base shelf shaped to its footprint. The result is a camera positioned at the correct presentation height with no visible wiring and minimal protrusion from the wall plane. The mount supports an extensive list of round-base PTZ cameras published by the vendor, including the Sony SRG-A12, SRG-A40, SRG-120DH, SRG-X40UH and SRG-300H; Panasonic AW-HE40, AW-UE40, AW-HE42, AW-HE60, AW-UE70 and AW-UN70; Lumens VC-A50P/PN, VC-A51S, VC-A52S, VC-A60S, VC-A61P and VC-A70H; AVer CAM520 PRO and CAM540 PRO; PTZOptics 12X/20X/30X SDI and USB models; QSC PTZ 12x72 and PTZ 20x60; Marshall CV620; Logitech PTZ PRO 2; HP Poly EagleEye IV USB; and the Cisco PTZ4K. It also pairs naturally with SCT camera extension kits, which carry video, control, and power over a single CAT cable concealed within the wall. Per the vendor, ADA protrusion compliance is unlikely given the depth of cameras in this category, so verify wall depth and applicable codes during design. Finish options are denoted by the SKU suffix.

Key Features

• Universal Round-Base Compatibility — One mount covers dozens of round-base PTZ cameras from Sony, Panasonic, Lumens, AVer, PTZOptics, QSC, Marshall, Logitech, HP Poly, and Cisco.
• Recessed In-Wall Design — The backbox sets the camera into the wall plane for a clean, architectural installation.
• Customizable Base Shelf — The shelf matches the camera's contoured base so it seats securely without improvised adapters.
• Concealed Cable Management — Video, power, and control wiring terminate inside the backbox, hidden from view.
• Finish Options — Finish variants (SKU suffix) blend with wall colors and interior design standards.
• Extension-Kit Friendly — Works with SCT camera extension solutions for long single-cable runs back to the equipment rack.

Typical Applications

• Boardrooms and executive conference rooms with design-sensitive walls
• Training rooms and all-hands rooms standardized on PTZ cameras
• House of worship venues using broadcast-style PTZ capture
• Government spaces requiring concealed cabling
• Auditoriums and multi-purpose rooms with mixed-vendor camera fleets

Technical Specifications

Frequently Asked Questions

Will the RCR-UNI fit my PTZ camera?
It supports standard round-base PTZ cameras; the vendor's published list spans Sony, Panasonic, Lumens, AVer, PTZOptics, QSC, Marshall, Logitech, HP Poly, and Cisco models. For rectangular-base cameras, specify the RCR-URM instead.

How does it differ from the RCR-URM?
The RCR-UNI base shelf fits round camera bases; the RCR-URM fits rectangular bases such as the HP Poly E60/E70 and AVer TR series. Both share the RCR Series recessed backbox design.

Can I run the camera over a long cable distance?
Yes. Pair the mount with an SCT camera extension kit to deliver video, control, and power over a single CAT cable up to 100 meters, all concealed inside the wall.

Is the installation ADA compliant?
Sound Control Technologies notes ADA protrusion compliance is unlikely due to the depth of cameras in this category. Review camera depth and local code requirements with your AV system designer.

How do I confirm finish and lead time?
Finish options are designated by the SKU suffix. Contact our sales team for finish confirmation, project pricing, and availability.
