Sound Control Technologies RCR-CQC – Recessed Wall Mount for Cisco Quad Camera

Product Overview

The Sound Control Technologies RCR-CQC is a recessed wall mount for the Cisco Quad Camera, recessing the intelligent multi-lens camera into the wall for a flush, architectural finish in Cisco Room Kit Pro and Codec Pro/EQ deployments. As part of the SCT RCR Series of in-wall camera mounts, it combines a wall backbox with a shelf profile matched to the Quad Camera. Integrators specify the RCR-CQC when a boardroom or large conference room design calls for the Quad Camera below or above the display without a surface-mounted bracket.

Product Description

The Cisco Quad Camera is a wide-format speaker-tracking camera typically installed at display height, where a surface bracket protrudes into the room and exposes cabling. The RCR-CQC solves both problems: its backbox recesses into the wall cavity, the Quad Camera seats on a matched shelf, and HDMI, Ethernet, and power cabling terminate inside the enclosure out of sight. The result is a clean wall line with the camera correctly positioned for participant framing and speaker tracking. The mount complements SCT's RC8 camera extension kit for the Cisco Quad Camera, which carries HDMI, Ethernet, and power over a single CAT cable up to 100 meters, allowing the codec to live in an equipment rack far from the room. Recessing the camera also protects it from incidental contact in high-traffic commercial meeting spaces and returns credenza depth to the room layout. Per the vendor, ADA protrusion compliance is unlikely due to the depth of cameras in this category; confirm wall depth, blocking, and code requirements during design. For pole-mounted ceiling installation of the same camera, see the companion SCT RCP-CQC pole mount.

Key Features

• Cisco Quad Camera Specific — The shelf and opening are dimensioned for the Cisco Quad Camera, ensuring a secure, correctly aligned seat.
• Recessed In-Wall Design — The backbox installs in the wall cavity so the camera presents flush with the finished wall.
• Concealed Cable Management — HDMI, Ethernet, and power cabling terminate inside the backbox with no visible wiring.
• Extension-Kit Companion — Pairs with the SCT RC8 extension kit to run the Quad Camera up to 100 meters from the codec over one CAT cable.
• Protects the Camera — Recessing removes the protruding camera from walkways and reduces accidental contact damage.
• Commercial-Grade Construction — Engineered for permanent installation by AV integrators in Cisco standardized estates.

Typical Applications

• Boardrooms built on Cisco Room Kit Pro or Codec Pro/EQ systems
• Large conference rooms requiring flush camera placement at the display wall
• All-hands rooms and town hall spaces using Quad Camera speaker tracking
• Government spaces with concealed-cabling and tamper-resistance requirements
• Commercial meeting spaces with design-led interiors

Technical Specifications

Frequently Asked Questions

Which camera does the RCR-CQC support?
It is purpose-built for the Cisco Quad Camera used with Cisco Room Kit Pro and Codec Pro/EQ systems.

Can the codec be located away from the room?
Yes. Pair the mount with the SCT RC8 extension kit to deliver HDMI, Ethernet, and power to the Quad Camera over a single CAT cable up to 100 meters from the codec.

Is there a ceiling option for the Quad Camera?
Yes. The SCT RCP-CQC pole mount handles ceiling installations of the same camera; the RCR-CQC is the in-wall recessed option.

What wall preparation is required?
The backbox recesses into a framed wall cavity. Review the SCT installation drawing for rough-in dimensions, blocking, and depth before construction.

How do I get pricing?
RCR Series mounts are quoted to project requirements. Contact our sales team to confirm configuration and lead time.
