Sound Control Technologies RC8-CQC-CB-2.0M – RemoteCam8 Extended Cable Bundle 2.0M

Product Overview

The Sound Control Technologies RC8-CQC-CB-2.0M is an extended-length camera cable bundle for RemoteCam8 (RC8) Cisco Quad Camera extension systems. It provides 2.0-meter camera-end cabling between the RC8-CE camera interface module and the Cisco Quad Camera, replacing the standard short cables supplied in RC8-CQC kits. AV integrators specify this bundle when the camera-end module must be mounted farther from the camera than the standard kit cabling allows.

Product Description

Standard RC8-CQC kits ship with 0.3-meter 90-degree camera cables, which assume the RC8-CE module mounts directly behind the Cisco Quad Camera. In installations where the module is concealed in a wall box, millwork, or an adjacent equipment pocket, the RC8-CQC-CB-2.0M extended cable bundle provides the additional reach at the camera end of the link. The bundle covers the camera-side connections of the RC8 system — HDMI video, UTP, and DC power — in matched 2.0-meter lengths engineered for the RC8 platform. Using vendor-matched cabling preserves the transparent link between the Quad Camera and Cisco Codec Plus, Codec EQ, Codec Pro, or SX80 codecs. A 1.0-meter version is available as the RC8-CQC-CB-1.0M for shorter offsets.

Key Features

• Extended 2.0-Meter Reach — Replaces the standard 0.3-meter camera cables when the RC8-CE module mounts away from the camera.
• Engineered for RemoteCam8 — Vendor-matched cable bundle preserves the transparent RC8 link to the Cisco Quad Camera.
• Complete Camera-End Set — Covers the HDMI, UTP, and power connections between the RC8-CE module and the camera.
• Clean Concealed Installations — Enables the camera-end module to be hidden in wall boxes, millwork, or equipment pockets.

Typical Applications

• Boardrooms with the RC8-CE module concealed in millwork or a wall box
• Conference rooms using RC-CUBBY or recessed camera mounts
• Commercial meeting spaces with non-standard Quad Camera mounting offsets

Technical Specifications

Frequently Asked Questions

When do I need the extended cable bundle?
When the RC8-CE camera-end module cannot mount directly behind the Cisco Quad Camera — for example, when it is concealed in a wall box or millwork — and the standard 0.3-meter kit cables are too short.

Is it compatible with RC8 Gen2 kits?
Yes. The bundle serves the camera-end connections of RC8-CQC series kits, including RC8 Gen2 configurations.

Does using longer camera cables affect the 100-meter link?
The CAT link between the RC8-CE and RC8-HE modules remains the primary extension run; this bundle only extends the short camera-side connections. Consult the SCT RC8 application guide for total cabling guidance.

What is included in an RC8-CQC kit versus this bundle?
Full RC8-CQC kits include the extension modules, head-end cables, power supply, and rack shelf. This bundle is the extended-length camera-end cable set only.
