Sound Control Technologies RC4-UNI-S – Multi-Manufacturer Camera Extension Kit with Rack Shelf
Sound Control Technologies RC4-UNI-S – Multi-Manufacturer Camera Extension Kit with Rack Shelf is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Sound Control Technologies RC4-UNI-S – Multi-Manufacturer Camera Ex...
Product Overview
The Sound Control Technologies RC4-UNI-S is a project pack bundling the RC4-UNI multi-manufacturer HDMI camera extension kit with an RC-RK2 1RU rack shelf. Supporting PTZ cameras from AVer, Lumens, Marshall, PTZOptics, Sony, and other manufacturers using 8-pin Mini-DIN Visca control, the system extends HDMI video, RS-232 Visca PTZ control, and 12V DC camera power up to 100 meters over a single CAT cable. The RC-RK2 rack shelf keeps the RC4-HE head-end module organized in a standard equipment rack.
Product Description
The RC4-UNI-S includes all RC4-UNI base kit components—RC4-CE, RC4-HE, comprehensive multi-brand cable set, and WPS-12 power supply—plus the RC-RK2 1RU rack shelf. The RC-RK2 accommodates up to two SCT head-end modules, making it practical when multiple camera extension systems share the same rack. The RC4 system carries HDMI video, RS-232 Visca control (8-pin Mini-DIN), and 12V camera power over one CAT cable. No programming is required. The -S suffix indicates the rack shelf is included without a camera wall mount. For a camera wall mount instead, see RC4-UNI-K. For both accessories, the RC4-UNI-KS provides the complete project pack.
Key Features
- RC-RK2 Rack Shelf Included — 1RU shelf for organized RC4-HE head-end module rack mounting; holds up to two SCT modules.
- Multi-Brand PTZ Compatibility — Supports cameras from AVer, Lumens, Marshall, PTZOptics, Sony, and other 8-pin Mini-DIN Visca manufacturers.
- Complete Cable Set — HDMI, Visca, and power cables for camera and head-end connections included.
- Single-CAT Extension up to 100m — HDMI, RS-232 Visca, and 12V power over one CAT cable.
- No Programming Required — Transparent RS-232 Visca PTZ control.
- Modular Design — RC4-CE and RC4-HE modules individually replaceable.
- Commercial-Grade — USA/Taiwan manufactured.
Typical Applications
- Conference room with PTZOptics or Lumens camera at extended distance requiring organized rack integration
- Multi-camera rack with two RC4-UNI extension systems sharing one RC-RK2 shelf
- Corporate or government space with dedicated AV rack and remote multi-brand PTZ camera
- Training room with Marshall or Sony PTZ camera extension requiring rack-mounted head end
Technical Specifications
| Specification | Detail |
|---|---|
| Model / SKU | RC4-UNI-S |
| Product Family | RemoteCam4™ (RC4) — HDMI + Visca Control + 12V Camera Power |
| Kit Contents | RC4-CE Camera Module, RC4-HE Head-End Module, full multi-brand cable set, WPS-12 Power Supply, RC-RK2 1RU Rack Shelf |
| Supported Cameras | AVer CAM520 Pro Advanced, Lumens VC-A series, Marshall CV620/CV630/CV730, PTZOptics PT series, Sony SRG-120DH/SRG-300H, and others — see compatibility guide |
| Signal Types Carried | HDMI video, RS-232 Visca PTZ control, 12V DC camera power |
| Maximum Extension Distance | 100 meters (328 ft) over CAT cable |
| Rack Shelf Capacity | 1RU; up to 2 SCT head-end modules |
| Unit of Measure | Each |
| Country of Origin | USA/Taiwan |
| MSRP | $2,515 |
Frequently Asked Questions
What does the -S suffix mean?
The -S suffix indicates this project pack includes the RC4-UNI base kit plus the RC-RK2 1RU rack shelf. No camera wall mount is included. For a camera wall mount, see RC4-UNI-K. For both, see RC4-UNI-KS.
Can two RC4-UNI-S head-end modules share the same RC-RK2 rack shelf?
Yes. The RC-RK2 shelf accommodates up to two SCT head-end modules in a single rack unit, making it practical when two camera extension systems are installed in the same rack.
What warranty and support terms apply?
Contact Creation Networks for current Sound Control Technologies warranty terms and support options for this product.
