Sound Control Technologies RC-SDA5+P60 – RemoteCam5 Extension Kit for Cisco Precision 60

Product Overview

The Sound Control Technologies RC-SDA5+P60 is a complete RemoteCam5 camera extension kit designed for the Cisco Precision 60 PTZ camera. It bundles the RC-SDA5+ BYOD Camera Bridge with Cisco Precision 60-specific cabling to convert HDMI video and audio to USB3 and translate UVC PTZ commands to IP Visca for full camera control over CAT cable. Commercial AV integrators can order a single SKU covering the complete head-end assembly and camera-specific cabling for Cisco Precision 60 deployments in conference rooms and boardrooms.

The kit replaces the RC5-HE head-end module and pairs with existing RC5-CE extension modules, supporting field upgrades without new cabling infrastructure.

Product Description

The RC-SDA5+P60 packages the RC-SDA5+ bridge with all cabling and terminations matched to the Cisco Precision 60 PTZ camera. The bridge accepts HDMI video and audio from the camera and delivers USB3 to the room codec or BYOD host, presenting the camera as a standard UVC device. UVC PTZ commands from the host are converted to IP Visca for full pan, tilt, and zoom control of the Cisco Precision 60, which uses IP-based PTZ protocol.

For AV system designers, the RC-SDA5+P60 simplifies project specifications with a single line item covering head-end electronics and all camera-specific cabling. Installation technicians can replace the RC5-HE head-end module with the RC-SDA5+ bridge without disturbing the RC5-CE extension module or the existing CAT cable run at the camera location. The kit is compatible with BYOD and BYOM workflows across Cisco and third-party codec environments.

Key Features

• Cisco Precision 60 Specific Kit — Includes all cabling and terminations matched to the Cisco Precision 60 camera for a complete installation without individual component sourcing.
• HDMI to USB3 Conversion — Converts Cisco Precision 60 HDMI video and audio to USB3 output for direct connection to codecs or BYOD hosts.
• IP Visca PTZ Control — Translates UVC PTZ commands to IP Visca for full pan, tilt, and zoom control of the Cisco Precision 60.
• RC5 Head-End Replacement — Replaces the RC5-HE module and pairs with existing RC5-CE extension modules for field upgrades without new cabling.
• BYOD/BYOM Ready — Presents the camera as a standard UVC USB3 device for use with BYOD laptops and room codecs.

Typical Applications

• Boardroom
• Conference room
• Commercial meeting space
• Government space
• Training room

Technical Specifications

Frequently Asked Questions

Is the Cisco Precision 60 the only camera this kit supports?

The RC-SDA5+P60 includes cabling specific to the Cisco Precision 60. For other cameras requiring IP Visca control, see the UNI, URM, and USM variants of the RC-SDA5+ series. Contact Creation Networks to confirm compatibility with your specific camera model.

Does this kit require an RC5-CE extension module?

Yes. The RC-SDA5+P60 includes the RC-SDA5+ bridge and camera-specific cabling. The RC5-CE extension module must be present at the camera end. It is not included in this kit.

Where can I get warranty and support information?

Contact Creation Networks for current Sound Control Technologies warranty terms and support options for the RC-SDA5+P60.
