Product Overview
The Sound Control Technologies RC-SDA5+CW4 is a complete RemoteCam5 camera extension kit designed for the Cisco PTZ-4K camera. It bundles the RC-SDA5+ BYOD Camera Bridge with Cisco PTZ-4K-specific cabling to convert HDMI video and audio to USB3 and translate UVC PTZ commands to IP Visca for full camera control over CAT cable infrastructure. AV integrators deploying Cisco PTZ-4K cameras in commercial conference rooms can order a single SKU that covers the full head-end assembly and all camera-specific cabling.
The kit replaces the RC5-HE head-end module and pairs with existing RC5-CE extension modules in the field, enabling upgrades without pulling new cable. The IP Visca PTZ control path distinguishes the RC-SDA5+ from the RC-SDA4+ series, making it the correct choice for cameras requiring IP-based PTZ control.
Product Description
The RC-SDA5+CW4 packages the RC-SDA5+ media bridge with all cabling required for a Cisco PTZ-4K installation. The bridge accepts HDMI video and audio from the camera and delivers USB3 to the room codec or BYOD host, presenting the camera as a standard UVC device. Incoming UVC PTZ commands from the host are converted to IP Visca for camera pan, tilt, and zoom control, which is the correct control protocol path for the Cisco PTZ-4K and other IP Visca-capable cameras.
For AV system designers, this kit eliminates the need to source and verify the RC-SDA5+ bridge and Cisco PTZ-4K cabling separately. Technicians can upgrade from RC5-HE head-end modules to the RC-SDA5+ by replacing only the rack-mounted electronics; the RC5-CE extension module and CAT cable run at the camera end remain intact. The kit is compatible with BYOD and BYOM conference room deployments.
Key Features
- Cisco PTZ-4K Specific Kit — Includes all cabling and terminations matched to the Cisco PTZ-4K camera for a complete, pre-verified installation.
- HDMI to USB3 Conversion — Converts camera HDMI video and audio to USB3 output, presenting the camera as a standard UVC device to any host.
- IP Visca PTZ Control — Translates UVC PTZ commands from the host to IP Visca, the required protocol for the Cisco PTZ-4K camera.
- RC5 Head-End Replacement — Replaces the RC5-HE module and works with installed RC5-CE extension modules without new cable infrastructure.
- BYOD/BYOM Compatible — Presents the camera as a UVC USB3 device for compatibility with BYOD laptops and room codecs.
Typical Applications
- Boardroom
- Conference room
- Training room
- Commercial meeting space
- Government space
Technical Specifications
| Specification | Detail |
|---|---|
| Model / SKU | RC-SDA5+CW4 |
| Kit Contents | RC-SDA5+ BYOD Camera Bridge + Cisco PTZ-4K-specific cabling and terminations |
| Video Input | HDMI (from Cisco PTZ-4K) |
| Video/Data Output | USB3 |
| PTZ Control | UVC PTZ (in) → IP Visca (out) |
| Infrastructure | CAT cable (pairs with RC5-CE extension module) |
| Compatible Camera | Cisco PTZ-4K |
| Compatible Extension Module | RC5-CE |
| Unit of Measure | Each |
| Country of Origin | USA/Taiwan |
Frequently Asked Questions
Why does this kit use IP Visca instead of RS-232 Visca?
The RC-SDA5+ series converts UVC PTZ commands to IP Visca, which is required for cameras like the Cisco PTZ-4K that use IP-based PTZ control. The RC-SDA4+ series outputs RS-232 Visca for cameras using serial PTZ control. Select the correct series based on your camera's PTZ protocol.
Does the RC-SDA5+CW4 replace my existing RC5-HE module?
Yes. The RC-SDA5+CW4 is a direct replacement for the RC5-HE head-end module and is designed to pair with the RC5-CE extension module already installed at the camera end.
Is the Cisco PTZ-4K the only camera this kit supports?
The RC-SDA5+CW4 includes cabling specific to the Cisco PTZ-4K. For other cameras requiring IP Visca control, see the RC-SDA5+UNI, URM, and USM variants. Contact Creation Networks to confirm compatibility with your specific camera model.
Where can I get warranty and support information?
Contact Creation Networks for current Sound Control Technologies warranty terms and support options for the RC-SDA5+CW4.
