Sound Control Technologies RC-SDA4+UNI – RemoteCam4 Kit for Multi-Manufacturer PTZ Cameras

Product Overview

The Sound Control Technologies RC-SDA4+UNI is a complete RemoteCam4 extension kit configured for multiple PTZ camera manufacturers including Lumens, Marshall, Sony, and PTZ Optics. It packages the RC-SDA4+ BYOD Camera Bridge with universal-fit cabling to convert HDMI video and audio to USB3 and translate UVC PTZ commands to RS-232 Visca, all transported over CAT cable infrastructure. AV integrators specifying systems with non-proprietary or multi-vendor camera selections can order a single SKU covering the full extension system for these camera families.

The kit replaces the RC4-HE head-end module in existing RemoteCam4 installations and pairs with the RC4-CE extension module already installed at the camera end, supporting field upgrades without disturbing existing cabling.

Product Description

The RC-SDA4+UNI bundles the RC-SDA4+ media bridge with universal camera-compatible cabling suited to Lumens, Marshall, Sony, and PTZ Optics PTZ cameras. The bridge takes HDMI video and audio input from the camera and delivers USB3 output to the room codec or BYOD host, presenting the camera as a standard UVC device. UVC PTZ control commands from the host are converted to RS-232 Visca for full pan, tilt, and zoom operation of the connected camera.

For AV system designers, the UNI kit reduces specification complexity when working with a range of PTZ camera brands, consolidating head-end bridge hardware and camera-specific cabling into one line item. The kit is compatible with BYOD and BYOM workflows and works with Cisco, Poly, and software-based codec environments. Signal transport over CAT cable matches the structured wiring found in most commercial conference room installations.

Key Features

• Multi-Manufacturer Compatibility — Includes cabling suited to Lumens, Marshall, Sony, and PTZ Optics PTZ cameras, supporting mixed-vendor AV deployments.
• HDMI to USB3 Conversion — Converts camera HDMI video and audio to USB3 output, presenting the camera as a UVC device to any connected host.
• RS-232 Visca PTZ Control — Translates UVC PTZ commands to RS-232 Visca for full pan, tilt, and zoom control of the connected camera.
• RC4 Head-End Replacement — Replaces the RC4-HE module and works with installed RC4-CE extension modules, enabling upgrades without new cable infrastructure.
• CAT Cable Transport — Signal and control travel over standard CAT cabling to the RC4-CE extension module at the camera location.

Typical Applications

• Boardroom
• Conference room
• Training room
• Commercial meeting space
• Government space

Technical Specifications

Frequently Asked Questions

Which specific camera models does the RC-SDA4+UNI support?

The RC-SDA4+UNI is configured for PTZ cameras from Lumens, Marshall, Sony, and PTZ Optics. Contact Creation Networks to verify compatibility with a specific camera model before ordering.

Is this kit compatible with existing RC4-CE extension modules?

Yes. The RC-SDA4+UNI replaces the RC4-HE head-end module and pairs with the RC4-CE extension module already installed at the camera end, preserving existing cable infrastructure.

Does this kit support BYOD conference room deployments?

Yes. The RC-SDA4+ bridge presents the connected camera as a standard UVC USB3 device, making it compatible with BYOD laptops and room codecs without additional drivers.

Where can I get warranty and support information?

Contact Creation Networks for current Sound Control Technologies warranty terms and support options for the RC-SDA4+UNI.
