Product Overview
The QSC QIO-ML24i is the highest-channel-count mic/line input expander in the QIO Series, providing 24 balanced mic/line inputs with 48V phantom power in a 1U rack-mount chassis. It enables large-scale microphone and line-level source integration at a distributed location — stage, lectern, or room-edge rack — without running long analog cables to the Core processor. The QIO-ML24i integrates natively with any Q-SYS Core and is managed in Q-SYS Designer Software. It is ideally suited for houses of worship, large conference facilities, auditoriums, performing arts venues, and enterprise campuses requiring substantial microphone channel count at a distributed rack position.
Key Features
- 24 balanced mic/line inputs with 48V phantom power — High-density microphone and line-level source integration in a single 1U chassis.
- Native Q-SYS integration — All 24 inputs fully routable in Q-SYS Designer; preamp gain, phantom power, and metering managed from the Core.
- 1U rack-mount — High-density input in a standard form factor; complements the QIO-L24o for full 24-channel I/O at a remote rack location.
- Distributed mic architecture — Place input rack at stage or FOH; Ethernet carries 24 channels to Core over a single cable.
Technical Specifications
| Specification | Value |
|---|---|
| Input Channels | 24 balanced mic/line with 48V phantom power |
| Network Interface | Q-SYS (Q-LAN) |
| Form Factor | 1U rack-mount |
| SKU | QIO-ML24i |
