QSC PL-SUB15 – Passive 15-in Installation Subwoofer, Black
Product Overview
The QSC PL-SUB15-BK is a 15-inch passive installation subwoofer designed for medium-to-large installed sound systems requiring powerful, extended bass in a more compact footprint than an 18-inch design. Its IP54-rated black enclosure, integrated rigging points, and IP65-rated input cup make it a versatile choice for flown or ground-stacked configurations in permanent venues.
Product Description
The PL-SUB15 houses a 15-inch woofer with a 4-inch voice coil in a bass-reflex enclosure built from exterior-grade plywood with polyurea paint. It delivers 124 dB continuous SPL and 136 dB peak SPL, with frequency response extending to 38 Hz (–6 dB). The enclosure includes four M10 bottom rigging points and four M10 side rigging points, enabling integration with the PL-CA12 loudspeaker for combined column arrays. The IP65-rated input cup provides dual Speakon NL4 connectors plus a 4-pole Euroblock for flexible amplifier connection. Like all PL Series subwoofers, the PL-SUB15 supports cardioid bass configuration when deployed in pairs or more, using Q-SYS processing to control directivity and minimize rear-stage energy buildup. The hydrophobic stainless steel mesh grille adds durability for environments with elevated humidity or dust exposure.
Key Features
- 15-inch woofer with 4-inch (100 mm) voice coil
- 96 dB sensitivity (1 W/1 m); 136 dB peak SPL
- 750 W continuous / 1500 W rated power handling at 8 ohms
- Frequency response: 41 Hz – 93 Hz (–3 dB); 38 Hz – 104 Hz (–6 dB)
- IP54-rated bass-reflex enclosure in exterior plywood with polyurea paint
- IP65-rated input cup with 2× Speakon NL4 + 1× 4-pole Euroblock
- 4× M10 bottom and 4× M10 side rigging points; links to PL-CA12
- Hydrophobic stainless steel mesh grille
- Omnidirectional or cardioid bass deployment (cardioid requires 2+ units)
- Nominal impedance: 8 ohms (minimum 6.8 ohms)
- RAL 9011 black finish
Typical Applications
- Houses of worship with medium-to-large sanctuaries
- Performing arts centers, theaters, and auditoriums
- Nightclubs, live music venues, and entertainment spaces
- Hotel ballrooms and conference centers
- Corporate event spaces and multipurpose rooms
- Flown or ground-stacked subwoofer configurations in permanent installations
Technical Specifications
| Woofer Size | 15 in (380 mm) |
|---|---|
| Voice Coil Diameter | 4 in (100 mm) |
| Enclosure Type | Passive bass-reflex |
| System Sensitivity | 96 dB (1 W/1 m) |
| Frequency Response (–3 dB) | 41 Hz – 93 Hz |
| Frequency Response (–6 dB) | 38 Hz – 104 Hz |
| Max SPL Continuous | 124 dB |
| Max SPL Peak | 136 dB |
| Power Handling — Continuous | 750 W @ 8 Ω |
| Power Handling — Rated | 1500 W @ 8 Ω |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 6.8 Ω |
| Connectors | 2× Speakon NL4, 1× Euroblock 4-pole (IP65 input cup) |
| Rigging | 4× M10 bottom, 4× M10 side; links to PL-CA12 |
| Dimensions (H × W × D) | 15 × 23.5 × 27.1 in (380 × 598 × 690 mm) |
| Weight (Net) | 80 lbs (36.3 kg) |
| Finish | Black (RAL 9011) |
| Enclosure Material | Exterior plywood, polyurea paint, IP54 |
| Grille | 16 GA steel, hydrophobic stainless steel mesh |
FAQs
- Can the PL-SUB15-BK be integrated with PL-CA12 loudspeakers?
- Yes. The PL-SUB15 includes side M10 rigging points specifically designed to link with the PL-CA12 coaxial loudspeaker, enabling compact, integrated column-array configurations.
- Does the PL-SUB15-BK support cardioid bass mode?
- Yes. When deployed in groups of two or more, cardioid bass configuration is achievable using Q-SYS DSP processing. This reduces rear-stage energy and focuses bass toward the audience area.
- What amplifier does QSC recommend for the PL-SUB15?
- QSC recommends the Q-SYS CX-Q 8K4 or CX-Q 4K4 amplifiers. Contact Creation Networks for amplifier matching and system design assistance.
- Is the PL-SUB15 suitable for outdoor use?
- The IP54-rated enclosure and hydrophobic grille mesh make it suitable for covered outdoor applications. Consult with Creation Networks for fully exposed outdoor use cases.
