QSC PL-SUB12 – Passive 12-in Installation Subwoofer, Black
Product Overview
The QSC PL-SUB12-BK is a 12-inch passive installation subwoofer designed for installations where a compact enclosure footprint is essential without sacrificing meaningful low-frequency output. With 122 dB continuous SPL, a frequency response reaching 41 Hz (–6 dB), and an IP54-rated black enclosure, the PL-SUB12 is a capable subwoofer solution for smaller venues and distributed bass systems.
Product Description
The PL-SUB12 houses a 12-inch woofer with a 3-inch voice coil in a compact bass-reflex cabinet constructed from exterior-grade plywood with polyurea paint. The 550 W continuous / 1100 W rated power handling and 92 dB sensitivity make it well suited for mid-sized spaces where a full-sized 15-inch or 18-inch subwoofer would be acoustically or physically inappropriate. The IP65-rated input cup provides dual Speakon NL4 connectors plus a 4-pole Euroblock, and four M10 rigging points on both the bottom and sides provide flexible installation and integration options. The PL-SUB12 operates in omnidirectional mode and pairs naturally with PL-CA coaxial or PL-DC directivity-control loudspeakers for complete installed system solutions managed through Q-SYS.
Key Features
- 12-inch woofer with 3-inch (76.2 mm) voice coil
- 92 dB sensitivity (1 W/1 m); 134 dB peak SPL
- 550 W continuous / 1100 W rated power handling at 8 ohms
- Frequency response: 44 Hz – 93 Hz (–3 dB); 41 Hz – 104 Hz (–6 dB)
- IP54-rated bass-reflex enclosure in exterior plywood with polyurea paint
- IP65-rated input cup with 2× Speakon NL4 + 1× 4-pole Euroblock
- 4× M10 bottom and 4× M10 side rigging points
- Compact footprint ideal for size-constrained installations
- Nominal impedance: 8 ohms (minimum 7.6 ohms)
- RAL 9011 black finish
Typical Applications
- Small-to-medium houses of worship
- Board rooms, conference rooms, and corporate AV systems
- Restaurants, retail spaces, and hospitality environments
- Classroom and lecture hall audio systems
- Distributed bass reinforcement in multi-zone installed systems
- Compact fill or accent subwoofer alongside larger main arrays
Technical Specifications
| Woofer Size | 12 in (300 mm) |
|---|---|
| Voice Coil Diameter | 3 in (76.2 mm) |
| Enclosure Type | Passive bass-reflex |
| System Sensitivity | 92 dB (1 W/1 m) |
| Frequency Response (–3 dB) | 44 Hz – 93 Hz |
| Frequency Response (–6 dB) | 41 Hz – 104 Hz |
| Max SPL Continuous | 122 dB |
| Max SPL Peak | 134 dB |
| Power Handling — Continuous | 550 W @ 8 Ω |
| Power Handling — Rated | 1100 W @ 8 Ω |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 7.6 Ω |
| Connectors | 2× Speakon NL4, 1× Euroblock 4-pole (IP65 input cup) |
| Rigging | 4× M10 bottom, 4× M10 side |
| Dimensions (H × W × D) | 13 × 20.6 × 24 in (333 × 525 × 610 mm) |
| Weight (Net) | 53.1 lbs (24.1 kg) |
| Finish | Black (RAL 9011) |
| Enclosure Material | Exterior plywood, polyurea paint, IP54 |
FAQs
- Is the PL-SUB12-BK suitable for medium-sized venues?
- Yes. The PL-SUB12 is designed for small-to-medium venues. For larger spaces, consider the PL-SUB15-BK or PL-SUB18-BK, available at Creation Networks.
- Does the PL-SUB12 support cardioid configuration?
- The PL-SUB12 is specified for omnidirectional operation only. For cardioid bass configurations, the PL-SUB15 or PL-SUB18 should be considered.
- What amplifiers work with the PL-SUB12-BK?
- QSC recommends the Q-SYS CX-Q 8K4 (2 units per channel) or CX-Q 4K4 (1 unit per channel). Contact Creation Networks for amplifier recommendations and system design support.
