QSC PL-SUB10 – Passive 10-in Installation Subwoofer, Black
Product Overview
The QSC PL-SUB10-BK is a 10-inch passive installation subwoofer offering a highly compact low-frequency solution for installed AV systems in smaller venues and distributed applications. Delivering 121 dB continuous SPL with a frequency response reaching 44 Hz (–6 dB), the PL-SUB10 provides meaningful bass extension in spaces where a larger subwoofer would be physically impractical.
Product Description
The PL-SUB10 houses a 10-inch woofer with a 3-inch voice coil in a compact bass-reflex cabinet built from exterior-grade plywood with polyurea paint. At just 41.8 lbs net weight and measuring 11 × 16.7 × 20 inches, the PL-SUB10 is among the most installation-friendly subwoofers in the PL Series lineup while still handling 450 W continuously and 900 W rated. The IP65-rated input cup accepts dual Speakon NL4 connectors and a 4-pole Euroblock. Four M10 rigging points on both the bottom and sides allow flexible mounting and stacking configurations. Like all PL Series loudspeakers, the PL-SUB10 integrates directly with Q-SYS for system-level processing, EQ, and monitoring, making it a natural fit in Q-SYS-managed installed sound ecosystems.
Key Features
- 10-inch woofer with 3-inch (76.2 mm) voice coil
- 89 dB sensitivity (1 W/1 m); 133 dB peak SPL
- 450 W continuous / 900 W rated power handling at 8 ohms
- Frequency response: 48 Hz – 94 Hz (–3 dB); 44 Hz – 104 Hz (–6 dB)
- IP54-rated bass-reflex enclosure in exterior plywood with polyurea paint
- IP65-rated input cup with 2× Speakon NL4 + 1× 4-pole Euroblock
- 4× M10 bottom and 4× M10 side rigging points
- Compact and lightweight: 41.8 lbs (19 kg) net weight
- Nominal impedance: 8 ohms (minimum 6.9 ohms)
- RAL 9011 black finish
- Native Q-SYS integration for system-level control and processing
Typical Applications
- Small venues, restaurants, and retail environments
- Corporate conference rooms and boardrooms
- Hotel lobbies, lounges, and smaller hospitality spaces
- Houses of worship with smaller sanctuaries
- Distributed bass reinforcement in multi-zone systems
- Fill subwoofer complementing larger main systems
Technical Specifications
| Woofer Size | 10 in (250 mm) |
|---|---|
| Voice Coil Diameter | 3 in (76.2 mm) |
| Enclosure Type | Passive bass-reflex |
| System Sensitivity | 89 dB (1 W/1 m) |
| Frequency Response (–3 dB) | 48 Hz – 94 Hz |
| Frequency Response (–6 dB) | 44 Hz – 104 Hz |
| Max SPL Continuous | 121 dB |
| Max SPL Peak | 133 dB |
| Power Handling — Continuous | 450 W @ 8 Ω |
| Power Handling — Rated | 900 W @ 8 Ω |
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 6.9 Ω |
| Connectors | 2× Speakon NL4, 1× Euroblock 4-pole (IP65 input cup) |
| Rigging | 4× M10 bottom, 4× M10 side |
| Dimensions (H × W × D) | 11 × 16.7 × 20 in (280 × 425 × 510 mm) |
| Weight (Net) | 41.8 lbs (19 kg) |
| Finish | Black (RAL 9011) |
| Enclosure Material | Exterior plywood, polyurea paint, IP54 |
FAQs
- What size venues is the PL-SUB10-BK best suited for?
- The PL-SUB10 is ideal for small venues, distributed audio systems, and applications where a 12-inch or larger subwoofer would be oversized. For medium and large venues, consider the PL-SUB12-BK, PL-SUB15-BK, or PL-SUB18-BK available at Creation Networks.
- Does the PL-SUB10 support cardioid bass configuration?
- The PL-SUB10 is specified for omnidirectional operation. For cardioid bass configurations, the PL-SUB15 or PL-SUB18 are the recommended options in the PL Series.
- How does the PL-SUB10 integrate with Q-SYS?
- The PL-SUB10 is designed as part of the Q-SYS ecosystem. When paired with a Q-SYS Core and CX-Q amplification, it supports system-level EQ, monitoring, and control through the Q-SYS Designer software environment.
- What amplifier is recommended for the PL-SUB10?
- QSC recommends the Q-SYS CX-Q 8K4 (2 units per channel) or CX-Q 4K4 (1 unit per channel). Contact Creation Networks for a complete system design consultation.
