QSC PL-LA8-AF – Array Frame for PL-LA8 Installation Line Array
Product Overview
The QSC PL-LA8-AF is a compact, high-strength array frame for flying or ground-stacking PL-LA8 installation line array loudspeakers. Built from zinc-plated steel with a UV- and salt-resistant powder coating, it supports both up-tilt and down-tilt configurations with a dense pattern of rigging points for precise array aiming. The PL-LA8-AF array frame is engineered for secure, accurate deployment in touring and fixed-install AV environments.
Product Description
The frame mounts in a normal orientation for maximum down-tilt or reversed for maximum up-tilt, with three sets of 11 rigging points spaced 50.8 mm apart for fine-grain angle control. It also supports secure ground-stacking of the array without additional base hardware. Purpose-built for the QSC PL-LA8, it suits performing arts centers, houses of worship, convention halls, and portable systems where compact, flexible rigging is required.
Key Features
- Rugged zinc-plated steel — Zinc-plated steel with powder coating rated for 1000 hours of UV exposure and 200 hours of salt spray for indoor and semi-exposed use.
- High-density rigging grid — Three sets of 11 rigging points at 50.8 mm spacing across the exterior rails and center spine for fine angle adjustment.
- Up-tilt and down-tilt — Mounts in normal orientation for maximum down-tilt or reversed for maximum up-tilt.
- Ground-stack capable — Allows secure ground-stacking of the PL-LA8 array without additional base hardware.
- Traceability ID — Each frame carries a unique traceability identifier for inventory and compliance documentation.
Technical Specifications
| Specification | Value |
|---|---|
| Model / SKU | PL-LA8-AF |
| Type | Line array rigging frame |
| Material | Zinc-plated steel |
| Coating | Powder coat rated 1000 h UV + 200 h salt spray |
| Rigging points | 3 sets of 11, 50.8 mm spacing |
| Mounting orientation | Normal (down-tilt) / reversed (up-tilt) |
| Ground stack | Supported |
| Compatibility | QSC PL-LA8 |
| Traceability | Unique identifier included |
