QSC PL-LA8-AF – Array Frame for PL-LA8, White
Product Overview
The QSC PL-LA8-AF-WH is the white array frame designed for the PL-LA8 line array loudspeaker. Supporting flown arrays of up to 14 PL-LA8 elements, this rigging frame provides 8 splay angle settings and 11 rigging pick points for precision coverage shaping in mid-size to large venue permanent installations — finished in white for all-white array configurations.
Product Description
Constructed from zinc-plated, powder-coated steel, the PL-LA8-AF-WH provides the structural backbone for flying PL-LA8 line array systems. The frame supports up to 14 PL-LA8 elements with a working load limit of 217.7 kg (480 lbs) at a 7:1 factor of safety (maximum total splay of 62.5°). Ground stacking of up to 4 PL-LA8 elements is also supported. Eight splay angle settings from 0.5° to 12° allow flexible array curvature, and 11 rigging pick points (use point #6 with the PL-LA8-PB pullback bar, sold separately) provide versatile rigging configurations. The frame downtilt range is 0° to 45°, with uptilt achievable by reversing the frame. At 30 lbs, the PL-LA8-AF is slightly lighter than the PL-LA12-AF. The white finish coordinates with white-finished PL-LA8 elements.
Key Features
- Compatible with QSC PL-LA8 line array loudspeaker
- Supports flown arrays of up to 14× PL-LA8 elements
- Ground stack capacity: 4× PL-LA8
- 8 splay angle settings: 0.5°, 1.5°, 3°, 4.5°, 6°, 8°, 10°, 12°
- 11 rigging pick points
- Frame downtilt: 0° to 45° (uptilt possible by reversing frame)
- Working load limit: 217.7 kg / 480 lbs (7:1 FoS, max 62.5° total splay)
- M10 pullback WLL (7:1): 92.1 kg / 203 lbs
- Zinc-plated, powder-coated steel construction
- Compatible with PL-LA8-PB pullback bar and EB3082-BK extension bar (sold separately)
- White finish for all-white array installations
- Frame weight: 30 lbs (13.6 kg)
Technical Specifications
| Compatible Speaker | QSC PL-LA8 |
|---|---|
| Max Flown Array Capacity | 14× PL-LA8 |
| Ground Stack Capacity | 4× PL-LA8 |
| Splay Angles | 0.5°, 1.5°, 3°, 4.5°, 6°, 8°, 10°, 12° |
| Rigging Pick Points | 11 points |
| Frame Downtilt Range | 0° to 45° |
| Working Load Limit (7:1 FoS) | 217.7 kg / 480 lbs (max 62.5° total splay) |
| Working Load Limit (10:1 FoS) | 169.2 kg / 373 lbs |
| M10 Pullback WLL (7:1) | 92.1 kg / 203 lbs |
| M10 Pullback WLL (10:1) | 64.4 kg / 142 lbs |
| Frame Weight | 30 lbs (13.6 kg) |
| Material | Zinc-plated, powder-coated steel |
| Finish | White |
| Accessories | PL-LA8-PB pullback bar, EB3082-BK extension bar (sold separately) |
