QSC PL-LA12-PB – Pullback Bar for PL-LA12 Installation Line Array
Product Overview
The QSC PL-LA12-PB is a pullback bar engineered to enhance directional control and system safety during rigging of PL-LA12 installation line array loudspeakers. Built from zinc-plated steel and coated for superior corrosion and UV resistance, it offers flexible attachment points and lightweight construction for accurate aiming and structural stability. The PL-LA12-PB pullback bar is a durable, easy-to-deploy solution for demanding professional AV installations.
Product Description
The pullback bar connects at either the top front or rear bottom of the PL-LA12 for optimal angling and rigging balance. It measures 22.95 in wide by 2.46 in high by 3.97 in deep and weighs no more than 5 lb (2.08 kg) for fast deployment and easy handling. Part of the same installation line array family as the QSC PL-LA8 system, it serves live event venues, theaters, houses of worship, and convention centers.
Key Features
- Durable zinc-plated steel — High-strength steel with zinc plating and powder coating rated for 1000 hours UV and 200 hours salt spray.
- Flexible attachment — Connects at the top front or rear bottom of the PL-LA12 for optimal angling and rigging balance.
- Lightweight and installer-friendly — Measures 22.95 in W x 2.46 in H x 3.97 in D and weighs no more than 5 lb (2.08 kg).
- Traceability ID — Each frame includes a unique identifier for installation documentation and asset tracking.
Technical Specifications
| Specification | Value |
|---|---|
| Model / SKU | PL-LA12-PB |
| Type | Pullback bar |
| Material | Zinc-plated steel |
| Coating | Powder coat rated 1000 h UV + 200 h salt spray |
| Mounting points | Top front or rear bottom |
| Dimensions (W x H x D) | 22.95 in x 2.46 in x 3.97 in |
| Weight | ≤ 5 lb (2.08 kg) |
| Compatibility | QSC PL-LA12 |
| Traceability | Unique identifier included |
