QSC PL-LA12-AF Array frame for use with PL-LA12

Array Frame for PL-LA12 Loudspeakers

Heavy-Duty Rigging Frame for Versatile Line Array and Subwoofer Deployment

The Array Frame for the PL-LA12 is a rugged, precision-engineered rigging accessory designed to simplify and secure the suspension or ground-stacking of PL-LA12 loudspeakers and PL-SUB18 subwoofers. Constructed from zinc-plated steel with advanced weather-resistant coatings, this frame supports flexible deployment strategies—including maximum down-tilt, up-tilt, flying, and stacking configurations—for demanding concert, venue, or installed sound environments.

Key Features and Benefits

• Durable Construction for Rigging Safety
  Built from zinc-plated steel with a powder coating rated for 1000 hours of UV exposure and 200 hours of salt spray resistance—ideal for both indoor and semi-exposed installations.
• Precision Rigging Design
  Features three sets of 11 rigging points, each spaced 50.8 mm apart, distributed across the frame's exterior and center spine for balanced, secure suspension.
• Tilt-Optimized Deployment
  Supports both:
• Normal position for maximum down-tilt of the PL-LA12 line array
• Reversed position for maximum up-tilt, enabling directional coverage in elevated arrays or balconies
• Dual Functionality
• Fly PL-LA12 arrays or PL-SUB18 subwoofers directly from the frame
• Ground stack PL-LA12 loudspeakers securely using the same rigging frame
• Compact Yet Strong Design
• Height: 3.8 in (97 mm)
• Width: 22.95 in (583 mm)
• Depth: 27.7 in (704 mm)
• Weight: ≤ 32 lb (14.3 kg) for manageable transport and setup
• Traceability Identifier Included
  Each frame includes a unique part ID for asset tracking, project documentation, and quality assurance compliance.

Ideal Applications

• Touring Sound Systems
• Fixed Installation Line Arrays
• Performing Arts Venues
• Houses of Worship
• Outdoor Event Rigs
• Corporate Event AV
• Convention Centers
• High-SPL Subwoofer Integration

Competitive Advantages

• Rigging Flexibility: Supports multiple mounting orientations and system configurations.
• Weather-Resistant Finish: Coated to meet long-term durability requirements in demanding environments.
• Integrated Subwoofer Support: One frame supports full-range and low-frequency deployment without needing separate hardware.
• Ground Stack & Fly Capable: Reduces system complexity and rigging time in hybrid deployments.
• Traceability Support: Streamlines inventory and compliance documentation for integrators and rental houses.
