QSC PL-DC26-FM Flush Mount Ceiling & walls for PL-DC26

Surface Mount Bracket Kit for PL-DC26 Loudspeakers

Precision-Machined Mounting Accessory for Secure and Flexible Installation

This rugged Surface Mount Bracket Kit is engineered specifically for use with the PL-DC26 loudspeaker, enabling flexible installation on walls or ceilings. Designed to meet commercial AV performance and durability standards, the kit features high-grade materials, corrosion-resistant finishing, and tool-less adjustability—making it ideal for professional installations in acoustically sensitive environments.

Key Features and Specifications

• Durable Construction:
  Includes three brackets, each manufactured from 1.5 mm thick galvanized cold-rolled steel (CRS) for optimal structural integrity.
• Protective Coating:
  Finished with a UV-resistant powder coating (1000-hour rating) and tested to 200 hours of salt spray resistance, ensuring long-term reliability in indoor or semi-exposed environments.
• Precision Angle Adjustability:
  Indexed mounting angles in 10° increments, allowing installers to fine-tune loudspeaker orientation for optimized coverage and aesthetics.
• Versatile Mounting Pattern:
  Supports standard 4-hole pattern (4 x 2.25" pitch, M6) for attachment to the loudspeaker’s top, bottom, or rear face—providing installation flexibility.
• Keyhole and Fastener System:
  Simplifies installation with a single fastener and keyhole design for secure, efficient mounting between the speaker and wall brackets.
• Traceability Identifier:
  Each bracket includes a unique traceability mark for quality assurance and inventory control.

Ideal Applications

• Boardrooms
• Auditoriums
• Conference Rooms
• Houses of Worship
• Government Facilities
• Lecture Halls
• Multi-purpose Meeting Spaces
• Commercial AV Installations

Competitive Advantages

• Corrosion-Resistant Finish: Withstands harsh installation environments better than painted or untreated hardware.
• Indexed Angle Control: Enables precise directional audio tuning—uncommon in many standard surface mounting kits.
• Simplified Installation: Reduces labor with minimal fasteners and intuitive alignment features.
• Universal Orientation Support: Compatible with multiple mounting faces of the PL-DC26 loudspeaker for diverse installation scenarios.
• AV System Integration Ready: Designed to meet commercial AV spec standards for integration in mission-critical environments.

Comparison Table
