QSC PL-DC24-YM – Yoke Mount for PL-DC24, White
Product Overview
The QSC PL-DC24-YM-WH is the white yoke mount accessory designed specifically for the PL-DC24 directivity-control loudspeaker. Compact and lightweight at 1.8 lbs, this steel yoke mount enables precise pan and tilt positioning for the PL-DC24 in permanent installations where white speaker hardware is required.
Product Description
The PL-DC24-YM-WH attaches to the PL-DC24 enclosure via two M8 threaded inserts. The yoke measures 14.28 inches wide with an arm height of 12.13 inches, proportioned to the PL-DC24's compact enclosure (8.7 lbs net). At just 1.8 lbs, the yoke brings the combined assembly to approximately 10.5 lbs — making this one of the lightest yoke-mounted speaker assemblies in the PL Series. The white finish coordinates with light-toned architectural environments. Consult Q-SYS rigging documentation and applicable local codes for load rating requirements and installation specifications.
Key Features
- Designed exclusively for the QSC PL-DC24 directivity-control loudspeaker
- Attaches via 2× M8 threaded inserts on the PL-DC24 enclosure
- Overall width: 14.28 in (362.8 mm)
- Arm height: 12.13 in (308 mm)
- Yoke weight: 1.8 lbs (0.82 kg)
- Combined assembly weight: approximately 10.5 lbs (4.76 kg)
- White finish for light-toned installation environments
- Steel construction
Technical Specifications
| Compatible Speaker | QSC PL-DC24 |
|---|---|
| Attachment | M8 thread × 2 places |
| Overall Width | 14.28 in (362.8 mm) |
| Arm Height | 12.13 in (308 mm) |
| Yoke Weight | 1.8 lbs (0.82 kg) |
| Finish | White |
| Material | Steel |
