QSC PL-DC12-YM – Yoke Mount for PL-DC12, White
Product Overview
The QSC PL-DC12-YM-WH is the white yoke mount accessory designed specifically for the PL-DC12 directivity-control loudspeaker. Providing precise pan and tilt adjustability for permanent installed sound systems, this steel yoke mount is finished in white to coordinate with light-toned architectural installations.
Product Description
The PL-DC12-YM-WH attaches to the PL-DC12 enclosure via two M8 threaded inserts and delivers the aim angle flexibility required for accurate coverage positioning in installed AV systems. The yoke spans 28.72 inches across the arms with an inner arm span of 24.00 inches and an arm height of 16.00 inches, sized to support the PL-DC12 (46.8 lbs). The yoke itself weighs 10.7 lbs, bringing the combined assembly to approximately 57.5 lbs. Consult Q-SYS rigging documentation and applicable local codes for load rating requirements and installation specifications.
Key Features
- Designed exclusively for the QSC PL-DC12 directivity-control loudspeaker
- Attaches via 2× M8 threaded inserts on the PL-DC12 enclosure
- Overall arm span: 28.72 in (729.6 mm)
- Inner arm span: 24.00 in (609.6 mm)
- Arm height: 16.00 in (406.4 mm)
- Yoke weight: 10.7 lbs (4.85 kg)
- White finish for light-toned installation environments
- Steel construction
Typical Applications
- House of worship
- Theater / performing arts venue
- Broadcast studio
- Convention center
- Auditorium
- Multi-purpose room
- Commercial meeting space (large format)
Technical Specifications
| Compatible Speaker | QSC PL-DC12 |
|---|---|
| Attachment | M8 thread × 2 places |
| Overall Width (arm span) | 28.72 in (729.6 mm) |
| Inner Arm Span | 24.00 in (609.6 mm) |
| Arm Height | 16.00 in (406.4 mm) |
| Yoke Weight | 10.7 lbs (4.85 kg) |
| Finish | White |
| Material | Steel |
Frequently Asked Questions
Which loudspeaker does the PL-DC12-YM-WH mount?
It is purpose-built for the QSC PL-DC12 point-source installation loudspeaker with directivity control. See the PL-DC12 product page for the companion loudspeaker.
Can it be mounted to a truss?
Yes. A 13 mm center hole supports clamp mounting, and 240 mm, 386.4 mm, and 589.6 mm hole patterns fit both US and European truss standards.
Is it suitable for outdoor or high-humidity installations?
The bracket uses galvanized cold-rolled steel with a powder coat rated for 1000 hours UV exposure and 200 hours salt spray, making it appropriate for demanding indoor and covered-outdoor environments. Confirm the PL-DC12 loudspeaker's own environmental rating for the application.
What load and rigging documentation should I follow?
Follow QSC's PL-DC12 mounting and rigging documentation and all applicable local codes. Overhead rigging should be verified by a qualified structural engineer.
What warranty applies?
Covered by QSC's applicable accessory warranty. Creation Networks provides fitment and rigging guidance at creationnetworks.net.
