QSC PL-DC12-YM – Yoke Mount for PL-DC12
Product Overview
The QSC PL-DC12-YM is a heavy-duty yoke mount bracket for secure, adaptable mounting of the QSC PL-DC12 installation loudspeaker. Built for demanding commercial environments, it combines high-strength galvanized construction, flexible speaker positioning, and universal truss compatibility. The PL-DC12-YM yoke mount supports venues that require precise audio coverage and robust rigging.
Product Description
Fabricated from 3.4 mm galvanized cold-rolled steel with a UV- and salt-spray-rated powder coating, the bracket provides a quick-install slot plus an additional fixed hole for compact positioning, and includes two rubber spacers for vibration isolation. A 13 mm center hole supports clamp mounting, while 240 mm, 386.4 mm, and 589.6 mm patterns fit both US and European trusses. Purpose-built for the QSC PL-DC12, it suits houses of worship, theaters, broadcast studios, and convention centers.
Key Features
- High-strength galvanized steel — Fabricated from 3.4 mm galvanized cold-rolled steel for maximum structural stability under load.
- Weather-resistant finish — Powder coating rated for 1000 hours of UV exposure and 200 hours of salt spray.
- Dual mounting options — Quick-install slot plus an additional fixed hole for compact positioning.
- Vibration isolation — Two round rubber spacers minimize vibration transmission for clean audio reproduction.
- Universal truss compatibility — 13 mm clamp hole plus 240 mm, 386.4 mm, and 589.6 mm truss-mounting patterns.
- Traceability ID — Unique part identifier for tracking and inventory control.
Typical Applications
- House of worship
- Theater / performing arts venue
- Broadcast studio
- Convention center
- Auditorium
- Multi-purpose room
- Commercial meeting space (large format)
Technical Specifications
| Specification | Value |
|---|---|
| Model / SKU | PL-DC12-YM |
| Type | Yoke mount bracket |
| Material | 3.4 mm galvanized cold-rolled steel |
| Coating | Powder coat rated 1000 h UV + 200 h salt spray |
| Speaker mounting | Quick-install slot + fixed hole |
| Vibration isolation | 2 rubber spacers included |
| Clamp hole | 13 mm |
| Truss spacing | 240 mm (11 x 7 mm oblong), 386.4 mm, 589.6 mm (7 x 20 mm slot) |
| Compatibility | QSC PL-DC12 |
| Traceability | Unique identifier included |
Frequently Asked Questions
Which loudspeaker does the PL-DC12-YM mount?
It is purpose-built for the QSC PL-DC12 point-source installation loudspeaker with directivity control. See the PL-DC12 product page for the companion loudspeaker.
Can it be mounted to a truss?
Yes. A 13 mm center hole supports clamp mounting, and 240 mm, 386.4 mm, and 589.6 mm hole patterns fit both US and European truss standards.
Is it suitable for outdoor or high-humidity installations?
The bracket uses galvanized cold-rolled steel with a powder coat rated for 1000 hours UV exposure and 200 hours salt spray, making it appropriate for demanding indoor and covered-outdoor environments. Confirm the PL-DC12 loudspeaker's own environmental rating for the application.
What load and rigging documentation should I follow?
Follow QSC's PL-DC12 mounting and rigging documentation and all applicable local codes. Overhead rigging should be verified by a qualified structural engineer.
What warranty applies?
Covered by QSC's applicable accessory warranty. Creation Networks provides fitment and rigging guidance at creationnetworks.net.
