QSC PL-CA15-YM – Yoke Mount for PL-CA15, White
Product Overview
The QSC PL-CA15-YM-WH is the white yoke mount accessory designed specifically for the PL-CA15 coaxial loudspeaker. Engineered to match the PL-CA15-WH's white RAL 9003 finish, this yoke mount enables precise pan and tilt positioning of the PL-CA15 in permanent installation environments where white speaker hardware is specified.
Product Description
The PL-CA15-YM-WH yoke mount attaches to the PL-CA15 enclosure via two M8 threaded inserts and provides the adjustable aim angle needed for coverage optimization in installed sound systems. The steel yoke spans 26.74 inches across the arms, accommodating the PL-CA15's 17.32-inch attachment width, and provides 16.00 inches of arm height for clearance. The white powder coat finish is matched to coordinate with the PL-CA15-WH loudspeaker, creating a cohesive appearance in light-toned architectural environments. The yoke adds approximately 10.8 lbs to the combined assembly weight. Consult the Q-SYS rigging documentation and applicable local codes for load rating and installation requirements.
Key Features
- Designed exclusively for the QSC PL-CA15 coaxial loudspeaker
- Attaches via 2× M8 threaded inserts on the PL-CA15 enclosure
- Overall arm span: 26.74 in (679.2 mm)
- Speaker attachment width: 17.32 in (440 mm)
- Arm height: 16.00 in (406.4 mm)
- Depth: 17.95 in (456 mm)
- Yoke weight: 10.8 lbs (4.9 kg)
- White finish coordinated with PL-CA15-WH (RAL 9003)
- Steel construction
Technical Specifications
| Compatible Speaker | QSC PL-CA15 |
|---|---|
| Attachment | M8 thread × 2 places |
| Overall Width (arm span) | 26.74 in (679.2 mm) |
| Speaker Attachment Width | 17.32 in (440 mm) |
| Arm Height | 16.00 in (406.4 mm) |
| Depth | 17.95 in (456 mm) |
| Yoke Weight | 10.8 lbs (4.9 kg) |
| Finish | White (matched to RAL 9003) |
| Material | Steel |
