QSC PL-CA12-YM – Yoke Mount for PL-CA12, White
Product Overview
The QSC PL-CA12-YM-WH is the white yoke mount accessory designed specifically for the PL-CA12 coaxial loudspeaker. Engineered to match the PL-CA12-WH's white finish, this yoke mount enables precise aim angle adjustment for optimal coverage in permanent installed sound systems requiring white speaker hardware.
Product Description
The PL-CA12-YM-WH attaches to the PL-CA12 enclosure via two M8 threaded inserts and provides the pan and tilt adjustability needed for precision coverage aiming. The steel yoke spans 24.28 inches across the arms to accommodate the PL-CA12's 15.75-inch attachment width. Weighing 9.8 lbs, the yoke brings the combined speaker-plus-yoke assembly to approximately 55.4 lbs. The white powder coat finish coordinates with the PL-CA12-WH loudspeaker for a consistent aesthetic in light-toned installation environments. Consult Q-SYS rigging documentation and applicable local codes for load rating and installation requirements.
Key Features
- Designed exclusively for the QSC PL-CA12 coaxial loudspeaker
- Attaches via 2× M8 threaded inserts on the PL-CA12 enclosure
- Overall arm span: 24.28 in (616.8 mm)
- Speaker attachment width: 15.75 in (400 mm)
- Depth: 13.80 in (350.4 mm)
- Yoke weight: 9.8 lbs (4.5 kg)
- White finish coordinated with PL-CA12-WH
- Steel construction
Technical Specifications
| Compatible Speaker | QSC PL-CA12 |
|---|---|
| Attachment | M8 thread × 2 places |
| Overall Width (arm span) | 24.28 in (616.8 mm) |
| Speaker Attachment Width | 15.75 in (400 mm) |
| Depth | 13.80 in (350.4 mm) |
| Yoke Weight | 9.8 lbs (4.5 kg) |
| Finish | White (matched to PL-CA12-WH) |
| Material | Steel |
