QSC CX-Q 8K4 – Four-Channel Q-SYS Network Amplifier (1250W/ch)
Product Overview
The QSC CX-Q 8K4 is the highest-power four-channel model in the CX-Q family of Q-SYS network amplifiers, with an 8,000 W power supply and Low-Z, 70 V, and 100 V direct drive on every channel. It is the right selection for large-format distributed audio, high-SPL main arrays, and subwoofer drive where the 4K4’s ceiling is insufficient. As a native Q-SYS component, it integrates into Q-SYS Designer Software for routing, processing, monitoring, and fault reporting, and shares the FlexAmp and FAST flexibility of the rest of the four-channel lineup.
Product Description
Built on QSC’s PL380 PowerLight platform with a 5th-generation Class-D hybrid powertrain, the CX-Q 8K4 delivers high-voltage and high-current operation with excellent thermal performance. FlexAmp distributes customized output levels per channel from a large shared reserve, while FAST (Flexible Amplifier Summing Technology) bridges, parallels, or combines channels for higher-voltage or higher-current loads — useful for subwoofers, delayed arrays, and high-SPL fill. Four mic/line inputs with +12 V phantom power provide additional Q-SYS on-ramps at the amplifier, and eight bi-directional GPIO connections enable third-party device control without a separate processor. A universal switchmode supply with active power factor correction and multi-stage sleep modes maintains efficiency across global line voltages. Four high-power network-addressable channels fit into 2RU. For lower-power needs, see the CX-Q 4K4; for more zones at lower per-channel power, see the eight-channel CX-Q 4K8.
Key Features
- Native Q-SYS integration — Drag-and-drop routing, processing, monitoring, and fault reporting in Q-SYS Designer.
- 8,000 W power supply, four channels — Highest four-channel power in the CX-Q lineup; Low-Z, 70 V, and 100 V on every channel.
- FlexAmp power distribution — Asymmetric per-channel output from a large shared reserve.
- FAST channel summing — Bridge, parallel, or bridge/parallel modes for subwoofers and high-SPL loads.
- Four mic/line inputs — +12 V phantom power; additional Q-SYS on-ramps at the amplifier.
- Eight bi-directional GPIO — Local third-party device control without a separate processor.
- Efficient power platform — PL380 PowerLight with active PFC and multi-stage sleep modes.
Typical Applications
- Auditorium — High-SPL main arrays and subwoofer drive under network control.
- All-hands room — Large-format amplification with significant headroom.
- House of worship — Main and subwoofer zones for large sanctuaries.
- Broadcast studio — High-output monitoring and reinforcement zones.
- Commercial meeting space — Demanding multi-zone amplification within Q-SYS.
Technical Specifications
| Channels | 4 (network-addressable) |
| Power supply (max) | 8,000 W |
| 8 Ω (max / continuous) | 1,250 W / 1,250 W |
| 4 Ω (max / continuous) | 2,400 W / 1,250 W |
| 70 V (max / continuous) | 1,250 W / 1,150 W |
| 100 V (max / continuous) | 1,250 W / 1,150 W |
| Frequency response (8 Ω) | 20 Hz – 20 kHz, +0.2 / -0.7 dB |
| Inputs | 4 mic/line (+12 V phantom), 3-pin Euro + Q-LAN |
| GPIO | 8 bi-directional |
| Power supply type | Universal 100–240 VAC, 50–60 Hz, active PFC |
| Dimensions (HWD) | 3.5 x 19 x 16 in (89 x 482 x 406 mm), 2RU |
| Net weight | 26 lb (11.8 kg) |
| Approvals | UL, CE, RoHS/WEEE, FCC Class B |
Max power: 20 ms, 1 kHz burst, single channel driven. Continuous: 20 Hz–20 kHz, all channels driven at the same load.
Frequently Asked Questions
When should I choose the 8K4 over the 4K4?
Choose the 8K4 for large-format speaker systems, high-SPL main arrays, or subwoofer drive that need more headroom than the 4K4’s 4,000 W supply provides.
Does it require a Q-SYS Core?
Yes — the CX-Q amplifiers are native Q-SYS components managed from a Q-SYS Core through Q-SYS Designer Software.
Can it drive subwoofers?
Yes. FAST allows channels to be bridged or paralleled for higher-voltage or higher-current loads such as subwoofers and high-SPL fill zones.
Can a single amplifier mix 70V/100V and low-impedance speakers?
Yes. Every channel offers Low-Z, 70 V, and 100 V direct drive, with FlexAmp distributing power per channel.
What about warranty and support?
Refer to QSC warranty terms for coverage. For Q-SYS design and purchasing questions, contact Creation Networks support.
