QSC CODP4 – Q-SYS Core 510i 4-Channel DataPort Output Card
Product Overview
The QSC CODP4 is a Q-SYS Type-II I/O card providing four DataPort analog output channels for the Core 510i processor. DataPort is QSC's high-density analog connection format used with DataPort-equipped amplifiers, including the DCA cinema series and ISA commercial amplifiers. The CODP4 lets the Core 510i drive these amplifiers directly over a single HD15 DataPort cable per amplifier, reducing the wiring complexity of large commercial and cinema audio installations.
Product Description
Where standard line outputs require individual XLR runs to each amplifier channel, a DataPort connection carries multiple channels plus monitoring over one cable. The CODP4 brings that capability to the Core 510i, ideal for facilities that already use QSC DataPort amplifiers such as the DCA1644 and DCA1824. It installs in any Type-II slot and combines with input and digital cards in the same chassis.
Key Features
- Four DataPort analog output channels — Drives QSC DataPort-equipped amplifiers directly from Q-SYS.
- Single-cable amplifier wiring — HD15 DataPort connection replaces multiple XLR runs per amplifier.
- Amplifier compatibility — Works with QSC DCA cinema and ISA commercial DataPort amplifiers.
- Type-II Q-SYS I/O card — Compatible with the Core 510i; combine with other Type-II cards in any slot.
Typical Applications
- Auditorium
- House of worship
- Commercial meeting space
- Multi-purpose room
Technical Specifications
| Type | Q-SYS Type-II I/O card |
| Output | 4 DataPort analog output channels |
| Connection | HD15 DataPort (single cable per amplifier) |
| Amplifier compatibility | QSC DataPort amplifiers (DCA cinema, ISA commercial) |
| Host processor | Q-SYS Core 510i (Type-II slot) |
Frequently Asked Questions
Which amplifiers can the CODP4 drive? QSC DataPort-equipped amplifiers, including the DCA cinema series and ISA commercial amplifiers.
What is the advantage of DataPort over line outputs? A single HD15 DataPort cable carries multiple channels plus monitoring per amplifier, reducing wiring versus individual XLR runs.
Can it be mixed with other I/O cards? Yes. It installs in any Core 510i Type-II slot and combines with input and digital cards.
What about warranty and support? Coverage follows QSC's published warranty terms. Contact Creation Networks support for configuration help.
