Product Overview
The QSC AD-S4T is a white pair of 4.5-inch two-way surface-mount loudspeakers supplied with X-Mount brackets for horizontal, vertical, wall, or ceiling installation. Voiced for consistency across the AcousticDesign range, these surface loudspeakers run on 70/100V distributed lines or 8-ohm circuits in foreground and background music applications.
Product Description
This QSC AD-S4T pair combines a 4.5-inch weather-treated paper-cone woofer with a 1-inch voice coil and a 0.75-inch silk dome tweeter on a DMT waveguide for even 120-degree conical coverage and improved off-axis response. Each loudspeaker handles 50W RMS with a peak maximum SPL of 110 dB and a stated frequency range of 68 Hz to 20 kHz (-10 dB). The rugged ABS enclosure exceeds IP54 ratings for dust and splash resistance, and a low-loss 70/100V transformer with 8-ohm bypass plus a sealed 4-pole Euroblock connector support reliable AV system integration. The award-winning X-Mount system installs at a range of angles with no slippage over time.
Key Features
- X-Mount installation — The supplied X-Mount brackets allow horizontal, vertical, wall, or ceiling mounting at a range of angles without slippage.
- 120-degree DMT coverage — The DMT waveguide delivers even 120-degree conical coverage with improved off-axis response.
- IP54 protection — The enclosure exceeds IP54 ratings for dust and splash resistance in exposed installations.
- 70/100V or 8-ohm operation — A low-loss transformer with 8-ohm bypass supports distributed and low-impedance systems.
- Sealed Euroblock input — A 4-pole Euroblock under a sealed input cover protects terminals from moisture.
- Intrinsic Correction ready — Voicing filters are available through Q-SYS processing or CXD amplifier platforms.
Typical Applications
- Commercial meeting space
- Multi-purpose room
- House of worship
- Training room
Technical Specifications
| Specification | Detail |
|---|---|
| Type | 4.5-inch 2-way surface-mount loudspeaker |
| Quantity | Pair (2) |
| Woofer | 4.5-inch weather-treated paper, 1-inch voice coil |
| Tweeter | 0.75-inch silk dome on DMT waveguide |
| Coverage | 120-degree conical |
| Frequency range | 68 Hz – 20 kHz (-10 dB) |
| Power handling | 50W RMS |
| Peak SPL | 110 dB |
| Operation | 70/100V or 8-ohm bypass |
| Protection | Exceeds IP54 |
| Connector | 4-pole Euroblock |
| Color | White |
Frequently Asked Questions
Can the AD-S4T be mounted outdoors?
It exceeds IP54 ratings for dust and splash resistance, suiting exposed and semi-protected areas; consult QSC ratings for fully outdoor exposure.
Does it support 70V distributed audio?
Yes. It includes a 70/100V transformer with an 8-ohm bypass tap for low-impedance use.
How does the X-Mount system work?
The supplied X-Mount bracket allows horizontal, vertical, wall, or ceiling mounting at a range of angles with no slippage over time.
What warranty applies?
Refer to QSC's AcousticDesign warranty terms or contact Creation Networks support for current coverage.
