QSC AC-S6T – AcousticCoverage 6.5-Inch 2-Way 30W Surface Speaker (Pair, Black)

Product Overview

The QSC AC-S6T is a 6.5-inch two-way AcousticCoverage Series surface-mount loudspeaker, sold as a black pair, voiced for enhanced clarity in the vocal range. With 70V/100V operation (and 8 Ω bypass), it suits paging, A/V conferencing reinforcement, and background music where ceiling mounting is not practical — concrete ceilings, walls, columns, and under-balcony positions. An included yoke bracket and rear Euroblock connector make surface installation straightforward.

Product Description

The AC-S6T pairs a 6.5-inch polypropylene woofer with a butyl-rubber surround and a 1-inch aluminum dome tweeter in a UV-treated ABS enclosure with a ported baffle. This two-way design delivers 130° conical coverage and a frequency range of 60 Hz – 20 kHz (-10 dB), handling 30 W RMS with a peak maximum SPL of 107 dB — offering increased clarity through the critical voice range and improved musicality over typical BGM-class products. A rear-panel 4-pole Euroblock connector supports easy input and loop-thru wiring, and the included yoke bracket simplifies aiming on walls or ceilings. Intrinsic Correction voicings are available through the Q-SYS Platform and CXD Series amplifiers. The AC-S6T is available in black and white.

Key Features

• 6.5-inch two-way surface speaker (pair) — Polypropylene woofer and 1-inch aluminum dome tweeter for clear voice and music.
• 130° conical coverage — Wide, even coverage that reduces the number of loudspeakers required.
• 60 Hz – 20 kHz range, 107 dB peak SPL — Handles 30 W RMS for paging, conferencing, and background music.
• 70V/100V with 8 Ω bypass — Distributed audio compatible or low-impedance operation.
• Included yoke bracket — Simplifies surface mounting and aiming on walls or ceilings.
• Rear Euroblock connector — 4-pole connector for easy input and loop-thru wiring.

Typical Applications

• Commercial meeting space — Surface coverage where ceiling mounting is impractical.
• Conference room — Wall- or column-mounted program audio and paging.
• Multi-purpose room — Flexible surface placement for changing layouts.
• Training room — Speech reinforcement and background music.
• House of worship — Under-balcony fill and wall-mounted distributed audio.

Technical Specifications

Frequently Asked Questions

How many speakers are included?
The AC-S6T is sold as a black pair, each with an included yoke mount bracket.

Does it support 70V/100V distributed audio?
Yes. It operates on 70V/100V distributed lines and offers an 8 Ω bypass for low-impedance use.

Where is a surface-mount speaker like this used?
In spaces where ceiling mounting is not possible or practical — concrete ceilings, walls, columns, and under-balcony fill.

Can it be tuned within a QSC system?
Yes. Intrinsic Correction voicings are available through the Q-SYS Platform and CXD Series amplifiers.

What about warranty and support?
Refer to QSC warranty terms for coverage. For system design and purchasing questions, contact Creation Networks support.
