QSC AC-S4T – AcousticCoverage 4-Inch 2-Way 16W Surface Speaker (Pair, Black)
QSC AC-S4T – AcousticCoverage 4-Inch 2-Way 16W Surface Speaker (Pair, Black) is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
QSC AC-S4T – AcousticCoverage 4-Inch 2-Way 16W Surface Speaker (Pai...
Product Overview
The QSC AC-S4T is a 4-inch two-way AcousticCoverage Series surface-mount loudspeaker, sold as a black pair, voiced for enhanced clarity in the vocal range. With 70V/100V operation and an 8 Ω bypass, it suits paging, A/V conferencing reinforcement, and background music in spaces where ceiling mounting is impractical — walls, columns, and concrete ceilings. The compact enclosure ships with a yoke bracket and a rear Euroblock connector for fast surface installation.
Product Description
The AC-S4T pairs a 4-inch (100 mm) polypropylene woofer with a butyl-rubber surround and a 1-inch aluminum dome tweeter in a UV-treated ABS enclosure with a ported baffle tuned for low-frequency extension down to 70 Hz. The two-way design provides 130° conical coverage across a 70 Hz – 20 kHz range, handles 16 watts, and reaches a peak maximum SPL of 103 dB. A 16-watt low-saturation 70V/100V transformer offers selectable taps with an 8 Ω bypass, and a rear 4-pole Euroblock connector with parallel output simplifies loop-thru wiring. Brass inserts accept the included yoke mount, and the rotatable grille logo eases horizontal or vertical installation. Intrinsic Correction voicings are available through the Q-SYS Platform and CXD Series amplifiers. The AC-S4T is available in black and white.
Key Features
- 4-inch two-way surface speaker (pair) — Polypropylene woofer and 1-inch aluminum dome tweeter in a compact enclosure.
- 130° conical coverage — Wide coverage that reduces the number of loudspeakers required in close proximity.
- 70 Hz – 20 kHz range, 103 dB peak SPL — Ported baffle extends low frequencies for clear voice and music.
- 70V/100V with 8 Ω bypass — 16-watt transformer with selectable taps for distributed audio or low-impedance use.
- Included yoke bracket — Brass inserts and thumb bolts for simple surface mounting and aiming.
- Rear Euroblock connector — 4-pole connector with parallel output for loop-thru wiring.
Typical Applications
- Commercial meeting space — Compact surface coverage where ceiling mounting is impractical.
- Conference room — Wall- or column-mounted program audio and paging.
- Huddle room — Small-room speech and background music.
- Training room — Speech reinforcement in close proximity.
- Multi-purpose room — Flexible surface placement for changing layouts.
Technical Specifications
| Configuration | Two-way surface-mount |
| LF transducer | 100 mm (4 in) polypropylene woofer |
| HF transducer | 25 mm (1 in) aluminum dome tweeter |
| Effective frequency range | 70 Hz – 20 kHz |
| Coverage | 130° conical (500 Hz – 5 kHz) |
| Rated noise power | 16 W |
| Sensitivity | 85 dB |
| Max continuous SPL | 97 dB |
| Max peak SPL | 103 dB |
| Rated impedance | 8 Ω |
| Recommended amplifier | 32 W |
| Transformer taps | 70V: 16, 8, 4, 2, 1 W; 100V: 16, 8, 4, 2 W; 8 Ω bypass |
| Connector | 4-pole Euroblock with parallel output |
| Enclosure / grille | UV-treated ABS / powder-coated steel |
| Ingress protection | IP-44 (indoor use) |
| Net weight (each) | 2.4 kg (5.3 lb) |
| Included | Yoke mount system |
| Finish | Black (RAL 9011) |
| Sold as | Pair |
Frequently Asked Questions
How many speakers are included?
The AC-S4T is sold as a black pair, each with an included yoke mount system.
Does it support 70V/100V distributed audio?
Yes. It includes a 16-watt 70V/100V transformer with selectable taps and an 8 Ω bypass for low-impedance use.
What amplifier power is recommended?
QSC recommends a 32-watt amplifier channel for the AC-S4T.
Can it be tuned within a QSC system?
Yes. Intrinsic Correction voicings are available through the Q-SYS Platform and CXD Series amplifiers.
What about warranty and support?
Refer to QSC warranty terms for coverage. For system design and purchasing questions, contact Creation Networks support.
