PTZOptics Move SE 30x Zoom PTZ Camera

Product Overview

The PTZOptics Move SE 30x PTZ camera is a 1080p NDI|HX2-certified PTZ camera with 30x optical zoom and built-in auto-tracking, designed for large-venue deployments in houses of worship, government spaces, auditoriums, and training rooms. It outputs simultaneously over 3G-SDI, HDMI, USB 3.0, and IP including NDI|HX2, with VISCA, PELCO-D, and PELCO-P control protocol support and PoE+ power for flexible installation. At $1,499, the Move SE 30x delivers professional-tier reach and feature depth for mid-range AV budgets.

Product Description

The PTZOptics Move SE 30x (PT30X-SE-GY-G3) is the highest-zoom model in PTZOptics' mid-range NDI camera line, providing 30x optical zoom with a 132.6mm maximum focal length and auto-tracking up to 120 feet — well-suited for large sanctuaries, auditoriums, courtrooms, and all-hands spaces where subjects may be distant from the camera position. The camera uses a Sony CMOS 1/2.8-inch sensor delivering 1080p@60fps across all outputs simultaneously: 3G-SDI via BNC, HDMI 1.3, USB 3.0 Type-C, and IP streaming including NDI|HX2, RTSP, RTMP, and SRT. NDI|HX2 certification means the camera is immediately discoverable by NDI-compatible switchers, production software, and monitoring tools on the same network without additional configuration. Control protocol support spans VISCA over IP, VISCA RS-232, PELCO-D, PELCO-P via RS-485, and IR remote (with front and rear IR receivers), giving AV integrators maximum compatibility with existing control systems. PoE (802.3af) power eliminates a separate power supply for most ceiling and wall mount installations. The built-in Presenter-Lock auto-tracking follows a designated presenter in multi-person scenes, and the Kensington lock slot provides physical security in shared or public-access spaces. Automatic video inversion detects and corrects the image for inverted mounting without manual configuration. With 255 preset positions at 0.1-degree accuracy, the camera supports multi-camera productions requiring repeatable shot recall. A 5-year limited parts and labor warranty and NDAA 2019 Section 889 compliance make it suitable for government, education, and corporate procurement programs. The Gen 3 platform receives ongoing firmware updates, with new features delivered via one-click updates throughout the product's operational lifespan.

Key Features

• 30x Optical Zoom — Focal range of 4.42mm ~ 132.6mm provides extreme reach for large sanctuaries, auditoriums, and conference halls where tight framing is required from distance.
• NDI|HX2 Certified — Native NDI|HX2 output enables automatic network discovery and integration with NDI-compatible production software, switchers, and monitoring tools.
• Multi-Output: 3G-SDI, HDMI, USB 3.0, IP — All outputs operate simultaneously, providing signals for SDI infrastructure, local display, USB capture, and IP network distribution.
• Built-In Auto-Tracking up to 120 Feet — Presenter-Lock identifies and follows a specific individual across large spaces, reducing the need for a dedicated camera operator.
• PoE Power (802.3af) — Powers the camera over standard Ethernet, simplifying cable infrastructure for ceiling and wall mounts.
• Full Control Protocol Support — VISCA over IP, VISCA RS-232, PELCO-D, PELCO-P, RS-485, and IR (front and rear) for compatibility with virtually any AV control system.
• SRT Streaming Support — Low-latency, error-corrected IP transport for remote production and contribution workflows over public internet connections.
• 255 Preset Positions — 0.1-degree recall accuracy for repeatable multi-camera production in live event and broadcast environments.
• Kensington Lock — Physical security for cameras deployed in public-access spaces including courtrooms, classrooms, and shared meeting rooms.
• 5-Year Limited Warranty — Parts and labor coverage for the full deployment lifecycle of a professional AV installation.
• NDAA 2019 Section 889 Compliant — Eligible for government and federally funded education procurement programs.

Typical Applications

• House of worship
• Auditorium
• Government space
• Training room
• All-hands room
• Broadcast studio

Technical Specifications

Frequently Asked Questions

Q: What NDI version does the Move SE support?

A: The Move SE Gen 3 supports NDI|HX2 (High Efficiency version 2) with the latest firmware update. NDI|HX2 provides improved image quality and lower latency compared to NDI|HX version 1. Native NDI enablement is included at no additional cost via firmware update.

Q: How does the Move SE 30x compare to the Link 4K 30x?

A: The Move SE 30x outputs 1080p@60fps and uses NDI|HX2 for IP video distribution. The Link 4K 30x outputs 4K@60fps and uses Dante AV-H for IP video distribution. The Move SE 30x is the better choice for NDI-based production environments and budget-conscious deployments; the Link 4K 30x is preferred for 4K workflows and Dante-networked facilities.

Q: Does the Move SE work with vMix and OBS?

A: Yes. The Move SE is compatible with vMix, OBS (via the PTZOptics OBS plugin), Wirecast, Tricaster, Livestream Studio, mimoLive, and the Elgato StreamDeck plugin. IP control uses VISCA over IP. NDI|HX2 output is directly discoverable by vMix and other NDI-compatible software.

Q: Is PoE or PoE+ required for the Move SE?

A: The Move SE 30x supports standard PoE (IEEE 802.3af), not PoE+. A standard 802.3af-compliant switch port or PoE injector providing 15.4W is sufficient. No PoE+ injector is required.

Q: Can the Move SE 30x be used for house of worship live streaming?

A: Yes. The Move SE 30x is a common choice for house of worship installations. Its 30x zoom provides tight framing of presenters from the back of large sanctuaries, and its NDI|HX2 output integrates with streaming software used in church productions. Auto-tracking reduces the need for a dedicated camera operator during services.

Q: What control systems are compatible with the Move SE?

A: The Move SE supports VISCA over IP (for software control), VISCA RS-232 (serial, Mini-DIN 8-pin), PELCO-D and PELCO-P over RS-485 (Phoenix connector, up to 3,937 feet cable run), and IR remote control. This covers virtually all commercial AV control systems and joystick controllers.

Q: Does the camera support preset tours?

A: Yes. The Move SE Gen 3 supports preset tour functionality, allowing the camera to cycle through a sequence of stored preset positions automatically. This is useful for unattended or single-operator productions where coverage of multiple fixed angles is needed.

Q: What physical security features does the Move SE include?

A: The Move SE includes a Kensington lock slot for physical security in shared or public-access environments such as classrooms, courtrooms, and conference rooms. The front and rear IR receivers allow operator control from any angle in the room.
