PTZOptics Move SE 12x Zoom PTZ Camera

Product Overview

The PTZOptics Move SE 12x PTZ camera is a 1080p NDI|HX2-certified PTZ camera with 12x optical zoom and a wide 72.5-degree horizontal field of view, designed for conference rooms, huddle rooms, training rooms, and compact worship spaces. It outputs simultaneously over 3G-SDI, HDMI, USB 3.0 Type-C, and IP including NDI|HX2 and SRT, with VISCA, PELCO-D, and PELCO-P control protocol support and PoE power. At $1,349, it is PTZOptics' most accessible NDI PTZ camera with full auto-tracking capability.

Product Description

The PTZOptics Move SE 12x (PT12X-SE-GY-G3) is the entry-level model in the Move SE Gen 3 lineup, combining a 1/2.8-inch Sony CMOS sensor with a 12x optical zoom lens (f = 4.1mm ~ 49.2mm) and a wide 72.5-degree horizontal field of view that captures full-room coverage in compact to medium-sized spaces without repositioning. The camera delivers 1080p@60fps simultaneously across 3G-SDI, HDMI 1.3, USB 3.0 Type-C, and IP streaming via NDI|HX2, RTSP, RTMP, and SRT, giving integrators complete signal flexibility from a single device. NDI|HX2 certification makes the camera immediately visible to NDI-compatible production software, switching platforms, and monitoring tools on the local network, enabling rapid integration into existing IP production workflows. VISCA over IP, VISCA RS-232, PELCO-D, PELCO-P (RS-485, up to 3,937 feet), and front/rear IR remote receivers cover the full range of commercial AV control protocols, providing compatibility with modern IP control systems and legacy serial infrastructure alike. Built-in Presenter-Lock auto-tracking identifies and follows a specific individual up to 60 feet, making it well-suited for close-to-medium distance applications such as conference rooms, training rooms, small houses of worship, and huddle spaces. PoE (802.3af) powers the camera over a single Ethernet cable, simplifying installation in ceiling or wall mount configurations. The Kensington lock slot provides physical security in shared or public-access environments. HETMA approval validates the camera for higher education deployments, and NDAA 2019 Section 889 compliance supports government and federally funded procurement. A 5-year limited parts and labor warranty and the Gen 3 platform's ongoing firmware update program protect the investment throughout the operational lifespan of the installation.

Key Features

• 12x Optical Zoom with 72.5-Degree Wide FOV — Captures full-room coverage in compact spaces; ideal for conference rooms, training rooms, and huddle spaces where the camera is close to the subject.
• NDI|HX2 Certified — Native NDI|HX2 output enables automatic network discovery and integration with NDI-compatible production software and IP switching infrastructure.
• Multi-Output: 3G-SDI, HDMI, USB 3.0, IP — All outputs operate simultaneously, serving SDI rooms, local displays, USB conferencing platforms, and IP production tools.
• Auto-Tracking up to 60 Feet — Presenter-Lock identifies and follows a specific individual in multi-person scenes for unattended or single-operator production in smaller spaces.
• PoE Power (802.3af) — Single-cable power and data delivery simplifies installation at ceiling and wall mount locations.
• SRT Streaming Support — Secure Reliable Transport for low-latency, error-corrected streaming over public internet connections.
• Full Control Protocol Support — VISCA over IP, VISCA RS-232, PELCO-D, PELCO-P, RS-485, and front/rear IR for compatibility with any commercial AV control system.
• 255 Preset Positions — 0.1-degree recall accuracy for repeatable multi-angle production in live event environments.
• Kensington Lock Slot — Physical security for deployments in classrooms, courtrooms, and shared meeting spaces.
• HETMA Approved — Independently evaluated and validated for higher education AV deployments.
• 5-Year Limited Warranty — Parts and labor coverage for the full lifecycle of a professional AV installation.

Typical Applications

• Conference room
• Huddle room
• Training room
• House of worship
• Government space
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Q: Is the Move SE 12x appropriate for a small conference room or huddle space?

A: Yes. The 12x model's 72.5-degree wide horizontal field of view is ideal for compact spaces where the camera is positioned 10 to 30 feet from the subject. It captures full-room coverage at wide angle and provides enough zoom reach for tight presenter framing at moderate distances.

Q: How does auto-tracking work on the Move SE 12x?

A: The Presenter-Lock system uses on-camera computer vision to identify and track a specific individual up to 60 feet from the camera. The operator selects the target subject from the web interface or connected control software, and the camera follows that person as they move, maintaining framing even when others are in the scene.

Q: What is HETMA approval and why is it relevant?

A: HETMA (Higher Education Technology Managers Alliance) evaluates AV equipment for suitability in higher education environments. The Move SE 12x received HETMA approval, with the committee noting its strong tracking performance and value relative to competing cameras costing two to three times more. This validation simplifies procurement decisions for colleges and universities.

Q: Can the Move SE 12x be used as a webcam for Zoom or Teams?

A: Yes. The USB 3.0 Type-C output presents the camera as a standard UVC (USB Video Class) device, compatible with Zoom, Microsoft Teams, Google Meet, and any platform that supports USB cameras. No driver installation is required.

Q: What is the NDI|HX2 bandwidth requirement?

A: NDI|HX2 is a compressed format designed for efficient bandwidth use over standard Ethernet. Typical bandwidth requirements are 10-20 Mbps per stream for 1080p@60fps, making it practical on 100Mbps networks alongside other data traffic without dedicated VLANs or QoS configuration in most deployments.

Q: How is the Move SE 12x powered?

A: The camera supports PoE (IEEE 802.3af), powered by a standard PoE switch port or injector. It also accepts a DC 12V power supply via the JEITA power jack for installations without PoE infrastructure.

Q: Does the Move SE 12x support preset tours?

A: Yes. The Gen 3 firmware includes preset tour functionality, allowing the camera to automatically cycle through stored preset positions on a defined schedule. This is useful for monitoring applications and single-operator productions where multiple angles need to be covered without continuous manual operation.
