Planar VM55MX-M2 55" 1920x1080 LCD Video Wall Display, 500 Nit - 998-2595-00

Product Overview

The Planar VM55MX-M2 (SKU 998-2595-00) is a 55-inch Full HD IPS LCD video wall display from the VM Series MX line, delivering 700 nit high-brightness output for demanding ambient light environments. With a tiled bezel width as small as 1.8mm, 4K@60Hz signal connectivity with HDCP 2.2, built-in video wall scaling for arrays up to 10x10, and 24/7 mission-critical reliability, the VM55MX-M2 is engineered for high-impact commercial digital signage, retail, hospitality, and control room applications where brightness is the primary differentiator.

Product Description

The Planar VM Series MX line is optimized for environments where ambient light creates visibility challenges. The VM55MX-M2 delivers 700 nits of brightness — 40% more than the standard LX-tier VM55 models — making it the specification of choice for atrium signage, retail environments with skylight or window exposure, sports bars, casino floors, and outdoor-facing digital displays where standard 500 nit output would be insufficient. The IPS panel technology provides outstanding color accuracy and contrast at wide viewing angles, ensuring consistent image quality for audiences across large open spaces. The M2 variant includes dual mounting options and OPS (Open Pluggable Specification) slot support for seamless integration of digital signage media players. Built-in video wall scaling supports configurations up to 10x10 (100 displays), with multiple daisy-chain signal support across DisplayPort, HDMI, DVI, and VGA. Source failover ensures continuous on-screen content even if a primary signal is lost. The fanless design eliminates acoustic noise in audience environments.

Key Features

• 55-inch Full HD (1920x1080) IPS LCD — VM Series MX high-brightness tier
• 700 nit brightness — optimized for high ambient light environments
• 1.8mm tiled bezel width option for near-seamless large-format arrays
• IPS technology — outstanding viewing angles and contrast
• 4K@60Hz DisplayPort and HDMI connectivity with HDCP 2.2
• Built-in video wall scaling — up to 10x10 display configurations
• OPS slot for integrated digital signage hardware
• Multiple daisy-chain signal support: DisplayPort, HDMI, DVI, VGA
• Source failover for uninterrupted display continuity
• Fanless design — silent commercial operation
• Landscape and portrait orientation support
• 24/7 mission-critical operation rated
• VESA mounting compatibility

Typical Applications

• Retail environments with high ambient or natural light (atriums, storefronts)
• Casino floors and gaming venue display walls
• Sports bars, hospitality, and entertainment venue video walls
• Corporate lobby and reception high-brightness signage
• University common area and student union display arrays
• Museum exhibit and gallery feature walls

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the difference between the VM55MX-M2 and the VM55LX-M?

Both are 55-inch Full HD IPS LCD video wall panels from the Planar VM Series with 1.8mm tiled bezel. The VM55MX-M2 (MX tier) delivers 700 nit brightness, making it the high-ambient-light choice. The VM55LX-M (LX tier, 998-1151-00) delivers 500 nit brightness and is the appropriate specification for controlled-light indoor environments where the premium 700 nit output is not required.

What video wall array sizes does the VM55MX-M2 support?

The built-in video wall scaling supports configurations up to 10x10 (100 displays). This eliminates the need for a standalone video wall controller in many straightforward multi-display applications.

Does the VM55MX-M2 support landscape and portrait orientations?

Yes. The VM Series supports both landscape and portrait mounting configurations, allowing vertical column or mixed-orientation video wall designs.

What is the OPS slot used for?

The OPS (Open Pluggable Specification) slot accepts compatible media player or compute modules, integrating digital signage playback hardware directly into the display chassis without external boxes or cabling.

Does the VM55MX-M2 have source failover?

Yes. Source failover automatically switches to an alternate input if the primary signal is lost, ensuring continuous on-screen content without operator intervention — critical for 24/7 public-facing displays.

What warranty does the VM55MX-M2 carry?

Planar VM Series products typically carry a 3-year advance exchange warranty. Confirm current warranty terms with Creation Networks at time of purchase.
