Planar VM Series Video Wall Mount – Landscape

Product Overview

The Planar VM Series Video Wall Mount is a dedicated mounting solution for Planar VM Series LCD video wall displays in landscape orientation. It uses a spring-loaded scissor extension and an integrated service kickstand to provide rear access to mounted displays, plus precise lateral alignment for seamless video wall registration. The mount ships with a universal hardware kit. This SKU is 998-0368-00.

Product Description

This Planar VM Series Video Wall Mount is engineered specifically for VM Series LCD video wall displays installed in landscape orientation. The spring-loaded scissor extension allows individual displays to be pulled out from the wall for service, and the integrated service kickstand holds the display in the extended position so a technician can access connections and electronics behind the panel without a second person holding it. Precise lateral alignment capability lets installers fine-tune the position of each display so adjacent panels register cleanly into a continuous video wall, which is important for minimizing visible offsets across a multi-display array. The mount secures to the VM Series display at four M6x1.0 VESA mounting locations and requires 5mm to 10mm of thread engagement for a secure connection. A universal hardware kit is included to support installation across compatible VM Series configurations. Spacers are available for use with various VM Series displays, with each spacer including a GapIt gauge, level, and instruction sheet to support consistent gap setting and leveling during installation. Because video wall mounting requirements vary by array size and structure, the number of mounts and any spacer accessories needed depend on the specific display layout. Review the broader Planar lineup through Creation Networks at our Planar collection. For per-SKU details such as display compatibility, weight ratings, and required spacers, contact Creation Networks to confirm.

Key Features

• VM Series landscape mounting — Purpose-built for Planar VM Series LCD video wall displays in landscape orientation.
• Spring-loaded scissor extension — Pulls individual displays away from the wall for service access.
• Integrated service kickstand — Holds the display extended for hands-free rear access during maintenance.
• Precise lateral alignment — Fine position adjustment for clean registration between adjacent displays.
• M6x1.0 VESA mounting — Four mounting locations with 5mm to 10mm thread engagement for secure attachment.
• Universal hardware kit included — Ships with hardware to support installation across compatible configurations.
• Spacer accessory support — Optional spacers include a GapIt gauge, level, and instruction sheet for consistent gap setting.

Typical Applications

• Commercial meeting space
• Conference room
• Boardroom
• Government space
• Broadcast studio
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

Which displays does this mount support? It is designed for Planar VM Series LCD video wall displays in landscape orientation. Contact Creation Networks to confirm your specific VM model.

How does it provide rear access? A spring-loaded scissor extension pulls the display from the wall, and an integrated kickstand holds it extended for hands-free service.

Can it align displays for a seamless wall? Yes. Precise lateral alignment lets installers register adjacent displays cleanly to minimize visible offsets.

What mounting hardware does it use? The mount attaches at four M6x1.0 VESA locations with 5mm to 10mm thread engagement and ships with a universal hardware kit.

Are spacers required? Spacers are available for various VM Series displays and include a GapIt gauge, level, and instruction sheet. Contact Creation Networks to confirm whether your layout needs them.
