Planar URX85-ERO-T UltraRes X Series 85" Ultra HD LED-LCD Touchscreen Display with ERO Glass - 998-3171-00

Product Overview

The Planar UltraRes X URX85-ERO-T is a TAA-compliant, commercial-grade 85-inch 4K UHD touchscreen display built for interactive environments requiring both high performance and physical durability. It combines ERO-LCD protective glass with Corning Gorilla Glass, 700 nits of brightness, HDR support, and multi-point touch capability to serve interactive meeting spaces, public kiosks, and high-traffic digital signage installations. Planar MediaPlex Plus processing supports up to four simultaneous content sources in configurable layouts. Rated for 24/7 continuous operation with a redundant power supply, it is engineered for mission-critical deployments where downtime is not acceptable.

Product Description

The Planar URX85-ERO-T (SKU: 998-3171-00) delivers an 85-inch diagonal 4K UHD (3840 x 2160) display area with the added protective layer of Planar ERO-LCD (Extended Ruggedness and Optics) glass incorporating Corning Gorilla Glass. This protective lamination eliminates the air gap between the protective layer and the LCD panel, improving contrast, reducing reflections, and providing a scratch- and impact-resistant surface appropriate for public-facing touch applications. At 700 nits, content remains legible under bright ambient lighting conditions common in lobbies, trade floors, and retail environments. Multi-point touch input supports collaborative annotation, interactive wayfinding, and touch-based control room applications without the design compromises of overlay-based touch systems.

The on-board OPS expansion slot accepts compute modules for signage processing or collaboration software, reducing cable complexity. Planar MediaPlex Plus processing delivers PIP, dual, triple, and quad-source configurations with storable presets for fast operator recall. The redundant power supply and 24/7 design rating make this display suitable for control rooms, security operations, and continuous-use corporate environments. TAA compliance supports government and institutional procurement.

Key Features

• 85-inch diagonal 4K UHD (3840 x 2160) touchscreen LED-LCD display
• Planar ERO-LCD with Corning Gorilla Glass for high-traffic durability
• Multi-point projected capacitive touch for interactive collaboration and kiosk applications
• 700 nits brightness with HDR and wide color gamut
• Planar MediaPlex Plus: PIP, dual, triple, quad-source layouts
• Redundant power supply for 24/7 continuous operation
• OPS slot for compute module integration
• ADA-compliant configuration with optional Planar Profile Mounting System
• TAA-compliant for government and institutional procurement
• Portrait and landscape orientation support
• Remote monitoring with email alert notifications

Typical Applications

• Interactive corporate meeting rooms and collaboration spaces
• Government and federal agency briefing rooms requiring TAA-compliant touch displays
• Public-facing kiosks and wayfinding in airports, transit, and healthcare facilities
• Command and control rooms with 24/7 continuous operation requirements
• Retail and trade show interactive product demonstrations
• Higher education classrooms and lecture theaters
• Security operations centers with multi-source monitoring needs

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What does ERO-LCD mean on the URX85-ERO-T?

ERO stands for Extended Ruggedness and Optics. The ERO-LCD layer bonds protective Corning Gorilla Glass directly to the LCD panel, eliminating the air gap that causes internal reflections and reducing the risk of damage from impacts, scratches, and contaminants in public environments.

How many touch points does the URX85-ERO-T support?

The display supports multi-point projected capacitive (PCAP) touch, enabling simultaneous input from multiple users during collaborative annotation or interactive presentations.

Can the URX85-ERO-T run continuously without interruption?

Yes. The display is rated for 24/7 continuous operation and includes a redundant power supply that eliminates single points of failure in the power delivery path.

Does the display support ADA compliance?

With the optional Planar Profile Mounting System, the URX85-ERO-T can be configured for ADA-compliant installation heights and angles.

Is the URX85-ERO-T TAA compliant?

Yes. It is fully TAA-compliant and suitable for federal, state, and local government procurement under GSA schedules.

What video input sources can be displayed simultaneously?

Using Planar MediaPlex Plus processing, the display supports up to four simultaneous input sources in PIP, dual, triple, or quad-split configurations, each independently adjustable.
