Planar URX100-ERO UltraRes X Series 100" 4K LCD Display - 998-2168-00

Product Overview

The Planar URX100-ERO is a TAA-compliant, 100-inch 4K UHD commercial LCD display built for always-on deployment in control rooms, corporate meeting spaces, and large-scale digital signage installations. As a core Planar UltraRes X 4K commercial display, it delivers 700-nit brightness, High Dynamic Range support, and wide color gamut reproduction in a ruggedized form factor featuring Planar ERO-LCD optically bonded Gorilla Glass. The non-touch configuration is optimized for applications where maximum image performance and ruggedness take priority over interactive input. Planar MediaPlex Plus on-board processing allows simultaneous viewing of up to four independent content sources with configurable preset layouts.

Product Description

The URX100-ERO addresses the practical requirements of large-format commercial display deployment: consistent brightness across the full 100-inch panel, protection against the physical contact inevitable in public environments, and the processing capability to serve as a standalone display node in multi-source AV systems. At 700 nits, the panel holds legibility in the high-ambient-light conditions found in lobbies, open-plan operations centers, and large conference rooms where lighting controls are limited. ERO-LCD optically bonds the Gorilla Glass cover to the panel, removing the air gap that would otherwise create internal reflection and reduce perceived contrast. MediaPlex Plus supports picture-in-picture, dual, triple, and quad layouts — presets for each can be stored and recalled with a single command, which significantly reduces operator interaction in control room environments. Portrait orientation capability expands the range of architectural and signage applications.

Key Features

• 100" diagonal 4K UHD (3840 x 2160) LCD display
• 700-nit brightness for brightly lit environments
• Planar ERO-LCD with Gorilla Glass protective overlay
• Planar MediaPlex Plus multi-source processing (PiP, dual, triple, quad)
• HDR-ready display
• Wide color gamut for accurate color reproduction
• Portrait and landscape orientation
• 24x7 duty cycle
• TAA compliant
• OPS expansion slot
• Remote monitoring with email alert capability

Typical Applications

• Network operations and command and control centers
• Large corporate conference rooms and boardrooms
• Government briefing and situation rooms
• Hospital and healthcare command centers
• University auditoriums and lecture theaters
• High-traffic lobby digital signage

Technical Specifications

Competitor Comparison

Frequently Asked Questions

How does the URX100-ERO differ from the URX100-ERO-T?

The URX100-ERO is the non-touch model. The URX100-ERO-T adds projected capacitive touch input for interactive applications. Both models share the same 100-inch 4K panel, ERO-LCD glass, and MediaPlex Plus processing.

Can this display run 24 hours a day, 7 days a week?

Yes. The URX100-ERO is rated and warranted for 24x7 continuous operation, making it suitable for control room and always-on digital signage deployments.

What inputs does the display support?

The display supports HDMI and DisplayPort inputs, as well as an OPS slot for embedded compute module integration. Exact input counts are detailed in Planar's full specification sheet.

Is the ERO glass field-replaceable?

ERO-LCD glass is optically bonded to the panel during manufacture and is not field-replaceable as a standalone component. In the event of damage, the display would require service or advance exchange.

What warranty does Planar provide?

Planar offers a 3-year advance exchange warranty on UltraRes X Series displays.
