Planar Simplicity M Series SLM75 - 75" LED-backlit LCD display...
Product Overview
The Planar Simplicity M Series SLM75 is a 75" 4K UHD commercial LCD display designed for digital signage deployments where large-format visual impact, ease of management, and affordability are priorities. With built-in media playback, an Android-based OS, fanless operation, and a slim logo-free bezel, it is purpose-built for retail, hospitality, healthcare, and corporate signage environments.
Product Description
The Planar SLM75 (SKU: 998-2766-00) delivers 4K UHD resolution at 3840x2160 on a direct-lit LED LCD panel with a 178-degree viewing angle and a 500-nit brightness rating. The 60Hz frame rate and 8ms response time ensure smooth content playback. Its proprietary Android 8.0-based operating system supports USB media playback and cloud-based digital signage applications directly, without requiring an external media player for basic deployments. HDCP 2.2 compliance over dual HDMI 2.0 inputs and 4K@60Hz support future-proofs content pipelines. A narrow 14.9mm logo-free bezel, 10Wx2 built-in speakers, RS-232/LAN/IR control, and fanless design make it a clean, reliable solution for commercial spaces. VESA 600x400mm mount compatible. Rated for up to 16 hours per day. 2-year warranty.
Key Features
- 75" diagonal direct-lit LED LCD, 3840x2160 (4K UHD) resolution
- 500 nits brightness, 1200:1 contrast ratio, 178-degree viewing angle
- 4K @ 60Hz via HDMI 2.0 (HDCP 2.2) — dual HDMI inputs
- Built-in media player with proprietary Android 8.0-based OS
- USB media playback for standalone signage without external player
- Fanless design for quiet, low-maintenance operation
- Narrow 14.9mm (0.6") logo-free bezel
- 10W x 2 built-in speakers
- Control via IR, RS-232, LAN, HDMI-CEC, and front keypad
- 16GB internal storage (4.5GB available)
- VESA 600x400mm mount compatible
- Landscape-only orientation
- FCC Class A, CE, cTUVus, RoHS certified
Typical Applications
- Retail digital signage — product promotions, wayfinding, and brand messaging
- Restaurant and quick-service digital menu boards
- Corporate reception areas and lobby displays
- Hotel and hospitality venue information boards
- Medical office waiting room displays
- Conference room and meeting space presentation displays
Technical Specifications
| SKU / Part Number | 998-2766-00 |
| Screen Size | 75" diagonal |
| Resolution | 3840 x 2160 (4K UHD) |
| Display Technology | Direct-lit LED LCD |
| Brightness | 500 nits |
| Contrast Ratio | 1200:1 |
| Viewing Angle | 178 degrees (H & V) |
| Frame Rate | 60Hz |
| Response Time | 8ms |
| Color Gamut | 72% NTSC, full 10-bit data path |
| Bezel Width | 14.9mm (0.6") logo-free |
| Orientation | Landscape only |
| Connectivity | HDMI 2.0 x2, DVI-D, VGA, USB media player |
| Display Control | IR, RS-232, LAN, HDMI-CEC, Keypad |
| Speakers | 10W x 2 built-in |
| Operating System | Proprietary OS based on Android 8.0 |
| Internal Storage | 16GB (4.5GB available) |
| Power Consumption | 184W typical (standby <0.5W) |
| Input Voltage | 100-240V, 50/60Hz |
| VESA Mount | 600 x 400mm |
| Weight | 91 lb (41 kg) |
| Recommended Usage | Up to 16 hours per day |
| Warranty | 2-year limited |
| Certifications | FCC Class A, CE, cTUVus, RoHS |
Competitor Comparison
| Feature | Planar SLM75 | Samsung QBR 75" | LG UH7F 75" | NEC ME751 |
|---|---|---|---|---|
| Screen Size | 75" | 75" | 75" | 75" |
| Resolution | 4K UHD | 4K UHD | 4K UHD | 4K UHD |
| Built-in Media Player | Yes — Android OS | Yes — Tizen OS | Yes — webOS | No |
| Brightness | 500 nits | 500 nits | 500 nits | 350 nits |
| Fanless | Yes | Yes | Yes | No |
| Logo-Free Bezel | Yes | No | No | No |
| 10-bit Color Path | Yes | Yes | Yes | Yes |
Frequently Asked Questions
- Does the SLM75 require an external media player?
- No. The SLM75 includes a built-in proprietary Android 8.0-based OS with 16GB of storage, supporting USB media playback and compatible cloud-based digital signage software without requiring an external player for basic deployments.
- Is the SLM75 rated for 24/7 operation?
- The SLM75 is recommended for up to 16 hours per day of operation. For true 24/7 continuous-duty applications, Planar's EP Series or Clarity Matrix G3 lineup is the appropriate choice.
- What mounting options are available?
- The SLM75 is compatible with VESA 600x400mm mounts. It also ships with cable clamps and carries handles for installation convenience.
- Does the SLM75 support 4K at 60Hz?
- Yes. The display accepts 4K UHD content at up to 60Hz via its HDMI 2.0 inputs with HDCP 2.2 compliance.
- Can the SLM75 be used in portrait orientation?
- No. The SLM75 is a landscape-only display. For portrait digital signage, consider a display from Planar's EP Series which supports both landscape and portrait orientations.
