Planar QE8650 - 86" large format 4K LCD display - 997-8797-01
Planar QE8650 - 86" large format 4K LCD display - 997-8797-01 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Planar QE8650 - 86" large format 4K LCD display - 997-8797-01
Product Overview
The Planar QE8650 is an 86-inch large-format 4K LCD display delivering 3840x2160 UHD resolution for high-impact digital signage, corporate collaboration, and command room applications. Supporting native 4K at 60Hz via HDMI 2.0 and DisplayPort 1.2, the QE8650 handles the latest 4K signal sources with HDCP 2.2-compliant inputs for protected content. Its fanless, wide-viewing-angle panel provides whisper-quiet 24/7 operation with a 1200:1 native contrast ratio and 178-degree horizontal and vertical viewing angles. TAA compliance qualifies the QE8650 for U.S. federal and government procurement requirements.
Product Description
The Planar QE8650 86-inch 4K LCD display offers the commanding screen real estate and commercial-grade durability demanded by enterprise AV integrators. With a native 3840x2160 resolution, 120Hz frame rate, and 6ms response time, the QE8650 delivers fluid, sharp imagery whether the content is live video, data dashboards, or high-motion digital signage. Quad-source simultaneous viewing allows operators to display four independent video feeds simultaneously in a 2x2 quad layout, with independent per-zone picture quality adjustments for precise image optimization. Remote monitoring via email alerts ensures operators are immediately notified of unexpected events in always-on installations. The QE8650 uses HDCP 2.2-compliant HDMI 2.0 inputs for compatibility with emerging 4K playback hardware, including 4K Blu-ray, streaming devices, and broadcast equipment. Crestron driver support simplifies integration for AV system designers and reduces programming time on complex installations. Operating without fans, the QE8650 eliminates noise and mechanical failure points while supporting 24/7 duty cycles. TAA compliance makes it a compliant choice for government agencies and organizations with U.S. trade compliance requirements. SKU 997-8797-01 carries a 3-year limited warranty.
Key Features
- 86-inch 4K UHD (3840x2160) large-format LCD display
- Native 4K at 60Hz via HDMI 2.0 and DisplayPort 1.2
- HDCP 2.2 compliant for protected 4K content
- 1200:1 native contrast ratio (20,000:1 dynamic)
- 178-degree horizontal and vertical viewing angles
- 120Hz frame rate with 6ms response time
- Quad-source simultaneous viewing with per-zone control
- Remote monitoring with email alert notifications
- Fanless operation for 24/7 quiet deployment
- Crestron driver support for simplified AV integration
- TAA compliant for federal and government procurement
- 3-year limited warranty | SKU: 997-8797-01
Typical Applications
- Corporate briefing centers and executive boardrooms
- Government and federal agency operations rooms (TAA required)
- University auditoriums and large classroom displays
- Retail flagship stores and high-traffic digital signage
- Control rooms, NOC, and SOC monitoring environments
- Hospitality lobbies and event venue displays
- Healthcare facility patient information systems
Technical Specifications
| Specification | Detail |
|---|---|
| Screen Size | 86 inches |
| Resolution | 3840 x 2160 (4K UHD) |
| Contrast Ratio | 1200:1 (20,000:1 dynamic) |
| Frame Rate | 120Hz |
| Response Time | 6ms |
| Viewing Angle | 178 degrees H / 178 degrees V |
| Pixel Pitch | 0.429 mm |
| HDMI | HDMI 2.0 (HDCP 2.2) |
| DisplayPort | DisplayPort 1.2 |
| Multi-source Viewing | 4 sources (quad layout) |
| Fanless | Yes |
| TAA Compliant | Yes |
| Warranty | 3-year limited |
| Part Number | 997-8797-01 |
Competitor Comparison
| Feature | Planar QE8650 | Samsung QMB-86" | LG UH7F-B 86" | NEC UN861 |
|---|---|---|---|---|
| Screen Size | 86" | 85" | 86" | 86" |
| 4K @ 60Hz | Yes | Yes | Yes | Yes |
| Native Contrast | 1200:1 | 1200:1 | 1200:1 | 1300:1 |
| TAA Compliant | Yes | No | No | No |
| Crestron Support | Yes | Yes | Yes | Yes |
| Fanless Operation | Yes | No | Yes | No |
Frequently Asked Questions
- Is the Planar QE8650 suitable for 24/7 operation?
- Yes. The QE8650 is engineered for 24/7 commercial duty cycles, making it appropriate for digital signage, command rooms, and any continuously operated display environment.
- Does the QE8650 support Crestron control systems?
- Yes. Planar provides Crestron drivers for the QE Series, reducing programming time and simplifying integration for AV system designers and control system programmers.
- What is the maximum refresh rate of the QE8650?
- The QE8650 supports a 120Hz frame rate with a 6ms response time, delivering fluid motion reproduction for video content and live data feeds.
- Can I view multiple video sources at the same time?
- Yes. The QE8650 supports quad-source simultaneous viewing, displaying four independent sources in a 2x2 layout with individual per-zone picture quality control.
- Is the QE8650 TAA compliant?
- Yes. The QE8650 is TAA (Trade Agreements Act) compliant and suitable for U.S. federal and government procurement via GSA Schedule.
- What is the native contrast ratio?
- The QE8650 delivers a 1200:1 native contrast ratio and a 20,000:1 dynamic contrast ratio for deep blacks and vibrant highlights across diverse content types.
