Planar MX55HDX-P 55"Clarity Matrix G2 800 nit LCD Video Wall Portrait - 997-8939-00

Product Overview

The Planar Clarity Matrix G2 MX55HDX-P is a 55" Full HD LCD video wall panel in portrait orientation, delivering 800 nit brightness for high-ambient-light commercial environments. With a tiled bezel width as low as 1.7mm and a 24/7 operational rating, this panel is purpose-built for mission-critical video wall deployments. The off-board electronics design reduces installed depth, weight, and thermal output while maximizing uptime. Portrait orientation makes it ideal for retail signage towers, digital menu boards, and vertical display arrays.

Product Description

The Planar Clarity Matrix G2 LCD video wall MX55HDX-P combines commercial-grade performance with portrait-optimized installation. At 800 nits, it outperforms many competing panels in naturally lit or high-ambient environments, maintaining image clarity across the full wall surface. The 1.7mm tiled bezel width—among the narrowest in the industry—ensures tile transitions are virtually invisible to viewers at typical distances.

The Planar EasyAxis Mounting System enables precise 6-axis panel-to-panel alignment and front-service access, reducing installation labor and ongoing maintenance costs. With an installed depth of just 3.6 inches, the MX55HDX-P fits into architecturally constrained wall cavities that prohibit deeper systems. This portrait-configured panel ships as the HDX variant, which does not include the -100 power supply module—ideal for installations supplying external power distribution.

Key Features

• 55" portrait-oriented commercial-grade LCD panel for video wall use
• 800 nit peak brightness for high-visibility environments
• Tiled bezel width from 1.7mm for near-seamless wall surface
• 24/7 continuous operation rating for mission-critical applications
• Off-board electronics: reduced depth, heat, and failure points
• Planar EasyAxis Mounting System with 6-axis alignment cams
• Front-service access mode for rapid panel maintenance
• Full HD 1920x1080 resolution, LED backlit
• Compatible with Planar Big Picture Plus video wall processing

Typical Applications

• Retail signage towers and portrait video wall arrays
• Digital menu boards in QSR and hospitality environments
• Corporate lobbies with vertical display configurations
• Transportation hubs requiring portrait-format information displays
• Broadcast and studio portrait orientation walls
• Control rooms with mixed landscape/portrait layouts

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What makes the MX55HDX-P different from the MX55HDU-P-100?

The MX55HDX-P (HDX variant) does not include the integrated -100 power supply module. The MX55HDU-P-100 includes the power supply, simplifying rack infrastructure for many installations.

Is this panel rated for portrait operation?

Yes. The MX55HDX-P is a purpose-configured portrait SKU, pre-set for vertical display orientation without requiring field rotation.

What is the minimum tiled bezel width?

The Clarity Matrix G2 MX line offers bezel widths ranging from 1.7mm to 3.7mm depending on the specific model variant.

Can this panel support touch input?

Touch capability is available on select Clarity Matrix G2 models with the optional ERO (Extended Ruggedness and Optics) overlay. Confirm touch support with your AV integrator.

What mounting system does the MX55HDX-P use?

It uses the Planar EasyAxis Mounting System, providing 6-axis adjustment for precise panel-to-panel alignment and an ultra-thin 3.6" installed depth.
