Planar MX55HDX 2x2 Clarity Matrix Multitouch 32pt touch video wall - 997-8537-00

Product Overview

The Planar MX55HDX is a 2x2 Clarity Matrix G2 LCD video wall system with 32-point multitouch capability, engineered for mission-critical control rooms, government operations, and interactive public environments. Built on the Planar Clarity Matrix G2 platform, it delivers a 1.7mm tiled bezel width, off-board electronics for maximum reliability, 4K input capability, and 10-bit color processing across four 55-inch Full HD LCD panels. The off-board design enables simplified service access and supports redundant power modules that maintain continuous operation even during a supply failure. Video extension up to 500 feet is built in, and the Planar EasyAxis mounting system enables precise panel alignment at an installed depth of just 3.6 inches.

Product Description

The Clarity Matrix G2 architecture separates the display electronics from the panel itself — a design choice that significantly improves mean time between failures and simplifies maintenance, since electronics can be serviced without disturbing the panel. This is particularly valuable in control room installations where downtime is operationally unacceptable. Redundant power supply modules further protect against unplanned outages. The MX55HDX model adds 32-point multitouch, enabling interactive use cases across the full 2x2 array — whiteboarding, touch navigation, and multi-user interaction are all supported. Big Picture Plus video wall processing handles content scaling from multiple sources across the tiled panels. For defense and government customers, the optional Clarity Matrix Fiber Video Extension provides secure fiber-based signal transport, incorporating USB extension without third-party extenders. WallNet health monitoring software with SNMP support provides remote visibility into system status.

Key Features

• 2x2 array of four 55" Full HD (1920 x 1080) LCD panels
• 32-point multitouch across the full video wall surface
• 1.7mm tiled bezel width
• 4K input capability with 10-bit color processing
• Planar Big Picture Plus video wall processing included
• Off-board electronics design for minimal downtime
• Redundant power supply modules
• Built-in video extension up to 500 feet (150 meters)
• Planar EasyAxis mounting system — 3.6" installed depth
• Planar WallNet monitoring with SNMP support
• No AC outlets required behind displays
• Single power supply can drive up to 8 displays
• Optional fiber video extension for secure signal transport
• ENERGY STAR certified, EU RoHS compliant

Typical Applications

• Mission-critical control rooms and network operations centers
• Government and military operations requiring secure signal transport
• Interactive public exhibits and experiential marketing installations
• Corporate briefing centers with multi-source display requirements
• Higher education visualization and collaboration centers
• Emergency management and dispatch centers

Technical Specifications

Competitor Comparison

Frequently Asked Questions

What is the benefit of the off-board electronics design?

By locating the signal processing electronics in a separate rack-mounted unit rather than inside the panel itself, Clarity Matrix G2 removes a primary source of heat and failure from behind the display. If an electronics module requires service, it can be replaced from the equipment rack without dismounting any panels, which is critical in 24x7 control room environments.

How does the built-in 500-foot video extension work?

The Clarity Matrix G2 uses proprietary Planar signal transport between the off-board electronics and the panel. This built-in extension eliminates the cost, latency, and reliability concerns of third-party HDBaseT or fiber extenders for distances up to 500 feet (150 meters).

Is the 32-point touch capable of multi-user interaction?

Yes. Thirty-two simultaneous touch points allow multiple users to interact with different areas of the video wall concurrently, which is applicable to collaborative whiteboarding, interactive exhibits, and multi-operator display scenarios.

What is the Planar WallNet monitoring system?

WallNet is Planar's video wall health and status monitoring software that integrates with the Clarity Matrix G2 system. It provides real-time visibility into panel status and supports SNMP for integration with enterprise network management platforms, allowing proactive identification of hardware issues before they result in downtime.

Can this system be expanded beyond 2x2?

Yes. The Clarity Matrix G2 platform supports larger configurations. Scaling beyond 2x2 requires additional panels, electronics modules, and mounting hardware. A single power supply module can drive up to eight displays, reducing rack space and power outlet requirements as the array grows.
