Planar LX55M-V-ERO 55" 1920X1080 Video Wall System - 998-1532-01
Product Overview
The Planar LX55M-V-ERO is a 55-inch LCD video wall panel with VESA-compatible mounting and Planar ERO optically-bonded glass, delivering Full HD 1920x1080 resolution at 500 nit brightness for commercial video wall deployments. The VESA configuration provides integrators with mounting flexibility to use standard or custom structural solutions while retaining the optical benefits of ERO bonded glass technology. Designed for 24/7 continuous operation, this commercial-grade display supports versatile tiling orientations and integrates cleanly into modern AV ecosystems via multiple input types. It is the preferred LX55M-ERO variant when third-party or custom mounting structures are a project requirement.
Product Description
The Planar LX55M-V-ERO (SKU: 998-1532-01) is the VESA-mounted configuration of the LX55M-ERO LCD video wall system, giving AV integrators the freedom to deploy this 55 inch video wall display within custom fabricated frames, motorized mounts, or existing mounting infrastructure. Full HD 1920x1080 resolution with 1080p scan format and a 10,000:1 dynamic contrast ratio delivers clear, vivid imagery for commercial signage and multi-source information displays. At 500 nit brightness, the LX55M-V-ERO maintains consistent visibility in standard commercial indoor lighting conditions. Planar ERO LCD video wall ERO glass is optically bonded to the display face, eliminating the reflective air gap and providing a ruggedized, impact-resistant front surface for video walls installed in accessible public areas. Connectivity is comprehensive: 4x HDMI inputs, DisplayPort, USB, Ethernet, and serial control cover virtually all modern AV integration requirements. Universal 120V and 230V AC input voltage support simplifies multi-region and international deployments. The VESA mount configuration means this panel is not limited to a single content orientation, giving integrators flexibility during system design.
Key Features
- 55-inch LCD video wall panel with VESA-compatible mounting
- Planar ERO optically-bonded glass for ruggedness and reflection elimination
- Full HD 1920x1080 resolution, 1080p scan format
- 500 nit brightness with 10,000:1 dynamic contrast ratio
- 34.6mm bezel width for tiled video wall arrays
- LED backlight for consistent panel illumination
- 4x HDMI inputs, DisplayPort, USB, Ethernet, serial
- 120V and 230V AC input voltage compatibility
- VESA mount for custom or third-party structural installations
- 24/7 commercial-grade continuous operation
Typical Applications
- Custom architectural video wall builds requiring VESA flexibility
- Retail environments with specialized mounting structures
- Corporate spaces using existing VESA-compatible mount infrastructure
- Museum and exhibition installations with custom fabricated frames
- Control rooms requiring non-standard mounting configurations
- Public venue information walls with motorized or adjustable mounts
Technical Specifications
| Specification | Detail |
|---|---|
| Model | LX55M-V-ERO |
| SKU / Part Number | 998-1532-01 |
| Screen Size | 55 inches |
| Mount Type | VESA compatible |
| Resolution | 1920 x 1080 (Full HD) |
| Brightness | 500 nit |
| Contrast Ratio | 10,000:1 dynamic |
| Bezel Width | 34.6mm |
| Backlight | LED |
| Scan Format | 1080p |
| HDMI Inputs | 4 |
| DisplayPort | Yes (1) |
| USB | Yes |
| Ethernet | Yes |
| Serial | Yes |
| Input Voltage | 120V / 230V AC |
| ERO Glass | Yes, optically bonded |
| Operation | 24/7 |
Competitor Comparison
| Feature | Planar LX55M-V-ERO | Samsung IA-Series 55" | LG LSCB Series 55" | NEC UN552 (UN-Series) |
|---|---|---|---|---|
| ERO / Bonded Glass | Yes | No | No | Optional |
| VESA Mount | Yes (native) | Yes | Yes | Yes |
| HDMI Inputs | 4 | 2 | 2 | 2 |
| Dynamic Contrast | 10,000:1 | Standard | Standard | Standard |
| 24/7 Rated | Yes | Yes | Yes | Yes |
| Dual Voltage | 120V / 230V | Auto | Auto | Auto |
Frequently Asked Questions
- What is the VESA mounting pattern for the LX55M-V-ERO?
- The LX55M-V-ERO supports standard VESA patterns for 55-inch commercial displays. Contact Creation Networks or refer to Planar's official datasheet for exact VESA hole spacing to match your chosen mounting hardware.
- Can the VESA version be installed in both landscape and portrait orientations?
- Yes. VESA mounting gives integrators the flexibility to install the panel in either landscape or portrait orientation. Proper cable management for the chosen orientation should be planned during the integration phase.
- How does the LX55M-V-ERO compare to the LX55M-L-ERO landscape model?
- The L-ERO ships with landscape-specific mounting hardware optimized for Planar's mounting ecosystem. The V-ERO provides VESA compatibility for custom or third-party mounting solutions. Both share the same panel specifications.
- Does ERO glass affect heat dissipation?
- No. The optically-bonded ERO glass does not materially affect the thermal performance of the display. The LX55M-V-ERO is rated for 24/7 operation with standard ventilation clearances per the installation guide.
- What control interfaces are available for system integration?
- The LX55M-V-ERO provides Ethernet (IP control), RS-232 serial, and USB interfaces for integration with AV control systems including Crestron, AMX, Extron, and custom automation platforms.
- Is this display TAA compliant?
- Contact Creation Networks for current TAA compliance status on the LX55M-V-ERO for government procurement requirements.
