Planar Leyard CDI LED Module – 3.9mm Pitch

Product Overview

The Planar Leyard CDI Series Indoor LED Module is a 3.9mm pixel-pitch direct-view display tile measuring 250 x 250mm with 64 x 64 pixel resolution. The 3.9mm pitch suits indoor video walls viewed at moderate to longer distances where larger surfaces are common. Its square 250 x 250mm module format supports straightforward tiling and alignment across an array. It is a service-replaceable component within the Leyard CDI indoor LED system.

Product Description

This module is a core building block of the Leyard CDI indoor LED platform, providing a 3.9mm pitch surface in a compact 250 x 250mm format. With 64 x 64 pixels per module, integrators can calculate total wall resolution predictably as modules are tiled into a larger array. The 3.9mm pitch is well matched to indoor environments viewed at moderate to longer distances, such as larger lobbies, atriums, and operations spaces. The square module geometry keeps seams consistent and simplifies layout planning across the wall. As a service-replaceable tile, the module supports module-level maintenance to keep fixed installations running with minimal downtime. It must be combined with matching CDI cabinets, modules, and system electronics to form a complete video wall. For cabinet pairing, mounting, and module quantity requirements, contact Creation Networks to confirm. View the complete Planar and Leyard direct-view LED range in the Planar collection.

Key Features

• 3.9mm pixel pitch — Indoor resolution suited to moderate and longer viewing distances.
• 250 x 250mm module — Compact square format for consistent tiling and alignment.
• 64 x 64 resolution — Defined per-module pixel count simplifies array resolution planning.
• Service-replaceable tile — Supports module-level maintenance to reduce downtime.
• Leyard CDI platform — Integrates with CDI cabinets and system electronics for a complete wall.

Technical Specifications
