Planar Leyard CDI – Indoor LED Module, 1.9mm Pitch

Product Overview

The Planar Leyard CDI Series LED module offers a 1.9mm pixel pitch in a 250 x 250mm format with 128 x 128 pixel resolution. Designed for indoor fine-pitch video walls, it serves as a serviceable tile within the CDI platform. The standardized module size simplifies array planning and scaling. It is available through Creation Networks for integrators building Planar and Leyard indoor LED video walls.

Product Description

This CDI Series module pairs a 1.9mm pixel pitch with a 250 x 250mm module size and 128 x 128 pixel matrix, giving integrators a predictable resolution-per-module figure for layout calculations. The fine pitch supports high-resolution content viewed at close indoor distances, making it suitable for corporate, control room, and signage applications. The CDI platform uses a modular, serviceable design in which individual modules tile to form a continuous display surface scaled to the room. Maintenance is supported within compatible structures, and brightness and color uniformity are managed at the system level through calibration across the array. Because per-SKU brightness, power, and structural details depend on the cabinet and overall configuration, integrators should contact Creation Networks to confirm specifications for a project. This SKU is the LED module only and does not include a cabinet, mounting structure, power supply, or controller. Additional Leyard CDI and Planar LED components are listed in our Planar collection. Correct pairing of modules, power, and signal distribution is required for a complete CDI installation.

Key Features

• 1.9mm pixel pitch — Fine pixel density supports high-resolution content at close indoor viewing distances.
• 250 x 250mm module — Standardized size simplifies array planning and predictable scaling.
• 128 x 128 resolution — Defined pixel matrix per module aids layout and content mapping.
• CDI platform — Serviceable module within the Leyard CDI indoor LED system.
• System calibration — Brightness and color uniformity managed across the assembled array.
• Indoor fine-pitch application — Suited to corporate, control room, and signage video walls.

Technical Specifications
