Planar Leyard CDI – 1.5mm Indoor LED Module

Product Overview

The Planar Leyard CDI Series indoor LED module is a 1.5mm pixel pitch tile measuring 250x250mm with 160x160 pixel resolution. This fine-pitch indoor LED module delivers high-density detail for close-range viewing in commercial video wall installations. The 250x250mm format supports flexible, scalable array sizing. It is a core component of the Planar Leyard CDI indoor direct-view LED platform.

Product Description

This Planar Leyard CDI 1.5mm LED module is a building block for high-resolution fine-pitch video walls in corporate, retail, and command-center environments. A 1.5mm pixel pitch with 160x160 resolution across a 250x250mm tile places this module among the higher-density indoor options, making it appropriate for applications where viewers stand close to the screen and image clarity is a priority. The 250x250mm module footprint lets integrators size displays in precise increments to match available wall space and resolution targets. As a modular tile, the component is intended for deployment within the CDI cabinet, mounting, and processing infrastructure that form a complete display system. Fine-pitch modules of this class are typically built into cabinets that support straightforward front or rear service. Pixel pitch, resolution, and module dimensions are confirmed from the manufacturer specification; full electrical and processing details depend on the system configuration, so contact Creation Networks to confirm requirements for your installation. For related fine-pitch LED components, browse the full Planar collection. Our team can assist with array layout, processing, and spare-part planning for Leyard CDI deployments.

Key Features

• 1.5mm Pixel Pitch — The fine pitch delivers high-density detail for close-range indoor viewing.
• 160x160 Resolution — The module provides 160x160 pixels across its 250x250mm active area.
• 250x250mm Format — The standardized square module enables precise, scalable video wall sizing.
• Indoor Fine-Pitch Design — The module targets premium interior applications where close-range clarity matters.
• CDI Series Compatibility — The module integrates with the Planar Leyard CDI indoor LED system infrastructure.
