Planar Cobra Series 0.6mm MicroLED Video Wall Cabinet - COBRA-06
The Planar Cobra Series is a 27-inch, 16:9 fine-pitch MicroLED video wall cabinet built on Planar's EverPixel architecture. At 0.6mm this is the finest pitch in the line, with a 960 x 540 cabinet resolution, so a 2x2 array lands at native 1920 x 1080.
Why it matters
- Every pixel has a backup. EverPixel builds pixel-level redundancy into the display, so a failed pixel does not show up as a dead spot on the wall.
- True MicroLED. TruMicro LEDs as small as 20 microns, with brightness uniformity of 97% or better and color uniformity of 98% or better.
- Holds up off-axis. 170-degree viewing angles with virtually no color shift, which matters in lobbies and control rooms where nobody stands dead center.
- Fewer cables, fewer controllers. Up to 5x the bandwidth of competing solutions means less hardware behind the wall and a simpler install.
- Built to be touched. A protective surface film handles casual contact and everyday wear, and touch interactivity is supported with compatible touch technology.
Specifications
| Pixel Pitch | 0.63mm |
| Cabinet Resolution | 960 x 540 |
| Cabinet Size (W x H x D) | 600 x 337.5 x 40.4mm | 23.62 x 13.29 x 1.6 in |
| Cabinet Diagonal | 688.4mm | 27.1 in |
| Cabinet Weight | 5.8 kg | 12.8 lbs |
| Module Configuration | 4 x 2 |
| Module Resolution | 240 x 270 |
| LEDs per Module | 64,800 |
| Scan Rate | 1:45 |
| Brightness, Maximum | 900 nits |
| Contrast Ratio | 30,000:1 |
| LED Refresh Rate | 3840 Hz |
| Frame Rate | 120 Hz max |
| LED Type | EverPixel with TruMicro |
| HDR Support | Yes |
| Viewing Angle | 170 degrees or greater, horizontal and vertical |
| Color Temperature | 3000 - 10,000K |
| Power Consumption, Maximum | 120 W per cabinet | 593 W/sq m | 55.1 W/sq ft |
| Line Voltage | 100-240V AC, 50/60Hz |
| Controller Compatibility | Planar WallDirector VC and ColorLight |
| Front Access Install/Service | Yes |
| Acoustic Noise | 30 dBA or less |
| ADA Compliant | Yes |
| Operating Temperature | 0 to 40 C | 32 to 104 F |
| Warranty | 5 year standard |
Specifications published by Planar Systems. Sold as an individual cabinet; wall size, controller and mount are configured per project.
