Planar 8-Out Video Controller – HDMI to CAT

Product Overview

The Planar 8-Out Video Controller (L version) is a video wall controller that accepts four HDMI inputs and distributes eight CAT outputs at 5Gb each. It supports HSL Loop for chained display connectivity and is TAA compliant for public-sector procurement. The controller is designed to drive Planar video wall displays that accept CAT-based signal distribution, simplifying cabling across an array. Output assignment and supported display models should be matched to the target wall.

Product Description

This Planar video controller centralizes source management for a video wall, taking up to four HDMI inputs and feeding eight CAT outputs that carry video to compatible Planar displays. CAT-based distribution allows longer, lower-cost cable runs between the controller and each display compared with direct video cabling, which is useful in walls where panels are spread across a structure. Each of the eight outputs operates at 5Gb, and HSL Loop support enables looped connectivity for streamlined chaining within the system. The L version designation identifies this CAT-output model within Planar's controller lineup; a corresponding fiber-output model is also available for longer runs. As a system component, the controller is selected based on the number of displays in the wall, the input sources required, and the distribution method preferred for the site. The unit is TAA compliant, supporting government and regulated procurement. To review compatible Planar video walls and the matching fiber-output controller, browse the full Planar collection at Creation Networks. Contact Creation Networks to confirm display compatibility, output mapping, and cabling design for your installation.

Key Features

• Four HDMI inputs — Accepts up to four source devices for distribution across the video wall.
• Eight CAT outputs — Distributes video to compatible Planar displays over CAT cabling.
• 5Gb per output — Each of the eight outputs operates at 5Gb for high-bandwidth signal delivery.
• HSL Loop support — Enables looped connectivity for streamlined chaining within the system.
• CAT-based cabling — Supports longer, lower-cost runs between controller and displays.
• TAA compliant — Supports government and regulated procurement requirements.

Typical Applications

• Broadcast studio
• Government space
• Commercial meeting space
• Auditorium
• Multi-purpose room

Technical Specifications

Frequently Asked Questions

What is the difference between the L version and the fiber version?
This L version provides CAT outputs, suited to standard runs. A fiber-output controller is available for longer-distance distribution. Contact Creation Networks to choose the right model.

How many displays can it drive?
It provides eight CAT outputs at 5Gb each. The number of displays depends on your wall layout and display model. Contact Creation Networks for output mapping.

What sources can I connect?
The controller accepts up to four HDMI inputs for distribution across the wall.

Which Planar displays is it compatible with?
It is designed for Planar video wall displays that accept CAT-based distribution. Contact Creation Networks to confirm compatibility with your displays.

What does HSL Loop do?
HSL Loop enables looped connectivity for streamlined chaining within the video wall system.

What warranty and support apply?
Contact Creation Networks for current warranty terms, firmware support, and integration assistance.
