Planar RPSM – Remote Power Supply Redundancy Module

Product Overview

The Planar Remote Power Supply Module (RPSM) is the redundancy module for Planar's Remote Power Supply (RPS) system, compatible with both the RPS110 and RPS220. It is required to add power redundancy to a remote power supply, supporting n+1 redundant operation and hot-swap capability. One RPSM is sold per power supply. The module is part of Planar's DirectLight LED video wall power architecture.

Product Description

This Planar RPSM provides the power redundancy module for the Remote Power Supply (RPS) family used to power Planar DirectLight LED video wall systems. Remote power supplies centralize LED wall power in a rack and feed cabinets over distance, with the RPS110 and RPS220 supporting n+1 redundant configurations and hot-swap module replacement. The RPSM is the module that enables that redundancy: adding an RPSM allows a power supply to continue delivering power if a module fails, and lets a failed module be replaced without taking the wall down. This is important for mission-aware installations such as control rooms, broadcast and command environments where uptime is a requirement rather than a preference. The RPSM is sold per power supply, so the quantity required depends on the number of RPS units and the redundancy level specified for the system. Because exact compatibility depends on the RPS model and firmware in your deployment, the configuration should be verified before ordering. Creation Networks supplies the full Planar DirectLight power, processing and cabinet lineup; browse our Planar collection. Contact Creation Networks to confirm RPS compatibility, required quantity and volume pricing.

Key Features

• Adds power redundancy — The RPSM is required to add redundancy to a Planar Remote Power Supply.
• RPS110 and RPS220 compatible — Works with both Remote Power Supply models in the RPS family.
• n+1 redundant operation — Supports n+1 redundant power configurations on the remote power supply.
• Hot-swap capability — The RPS architecture supports hot-swap module replacement to maintain uptime.
• Sold per power supply — One module is supplied per power supply for clear, scalable specification.
• DirectLight power architecture — Part of Planar's remote power system for DirectLight LED video walls.
• Uptime-focused design — Targeted at installations where continuous operation is required.

Typical Applications

• Control room and command center LED walls
• Broadcast and studio LED video walls
• Mission-aware corporate and operations displays
• Always-on signage and experience installations
• Any Planar DirectLight wall requiring power redundancy

Technical Specifications

Exact electrical specifications and compatibility depend on the RPS model and system configuration; contact Creation Networks to confirm.

Frequently Asked Questions

• What does the RPSM do? It is the module required to add power redundancy to a Planar Remote Power Supply, supporting n+1 operation.
• Which power supplies is it compatible with? The RPSM is compatible with both the RPS110 and RPS220.
• How many RPSM units do I need? The RPSM is sold per power supply; the quantity depends on the number of RPS units and your redundancy level. Creation Networks can confirm.
• Can a module be replaced without downtime? The RPS architecture supports hot-swap replacement to help maintain uptime.
• What is this used with? It is part of the Planar DirectLight remote power architecture for LED video walls.
• How do I confirm the right configuration? Contact Creation Networks to verify RPS compatibility, quantity and pricing for your system.
