Philips 65BDL3117P – 65" 4K UHD 750-Nit 24/7 P-Line Display
Philips 65BDL3117P – 65" 4K UHD 750-Nit 24/7 P-Line Display is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Philips 65BDL3117P – 65" 4K UHD 750-Nit 24/7 P-Line Display
Product Overview
The Philips 65BDL3117P is a 65" 4K UHD P-Line digital signage display built for demanding 24/7 commercial environments such as retail, transportation hubs, and food-and-beverage venues. Its 750 cd/m² high-brightness ADS panel keeps content readable in window-facing and brightly lit installations where standard 350–500 nit displays wash out. An integrated Intel SDM-L slot accepts a slim compute module for embedded media playback without external cabling. FailOver, tiling support, and full network control make it a dependable spec for unattended commercial deployment.
Product Description
Integrators planning high-ambient-light signage installations will appreciate the 750-nit output of the 65BDL3117P, paired with a 25% haze panel treatment that cuts reflections in storefront and atrium placements. The 3840 x 2160 ADS panel delivers 1.07 billion colors, 1200:1 typical contrast, and 178-degree viewing angles, with 4K @ 60Hz input accepted over HDMI 2.0 and DisplayPort 1.2. Philips also engineered this model to meet clinical compliance standards for grayscale performance (D-image), making it suitable for reviewing medical imagery in consultation rooms and lecture settings.
The connectivity set is designed for professional AV integration: three HDMI 2.0 inputs, DisplayPort 1.2 in and out, DVI-I, HDMI output, USB 2.0 with media playback, and microSD. HDMI, DisplayPort, RS232, and IR loop-through simplify daisy-chained installations, and the display supports tiled matrices up to 15x15 for video wall layouts. The SDM-L (Smart Display Module Large) slot embeds an Intel compute module flush inside the chassis, providing OPS-class intelligence in a slimmer profile — a practical upgrade path when content requirements grow. IT and facilities teams control the display over RJ45 or RS232 with CMND & Control, while FailOver automatically switches to a backup input if the primary source drops. The display is rated 24/7 in both landscape and portrait with a 50,000-hour MTBF, hidden lockable keypad controls, and pixel-shift panel protection. ENERGY STAR 8.0 certification, SmartPower energy management, and a 3-year warranty support procurement evaluation. Compare sizes and brightness tiers in the Philips collection at Creation Networks.
Key Features
- 750 cd/m² High-Brightness Panel — Content stays legible in storefronts, atriums, and other high-ambient-light commercial spaces.
- 4K UHD at 60Hz — 3840 x 2160 resolution with 1.07 billion colors renders detailed signage, schedules, and data dashboards clearly.
- True 24/7 Duty Cycle — Rated for continuous operation in landscape or portrait with a 50,000-hour MTBF and panel-saving functions.
- Intel SDM-L Slot — Embed a slim Smart Display Module compute unit inside the display for cable-free media playback and future upgrades.
- FailOver Input Protection — Automatic switching between primary and secondary inputs prevents blank screens during source failures.
- D-Image Grayscale Accuracy — Clinically compliant grayscale performance supports medical image review in consultation and lecture environments.
- Tiled Matrix up to 15x15 — Built-in tiling and DisplayPort/HDMI loop-through enable multi-display walls without external processors.
- Network and Serial Control — RJ45 and RS232C in/out with IR loop-through integrate with Crestron, Extron, and AMX control systems.
- Anti-Glare 25% Haze Finish — Reduced reflections improve readability near windows and overhead lighting.
- USB Media Playback — Play video, image, and audio content directly from USB for standalone signage without a player.
Typical Applications
- Commercial meeting space
- Auditorium
- All-hands room
- Boardroom
- Government space
- House of worship
- Training room
Technical Specifications
| Model | 65BDL3117P/00 (P-Line) |
| Screen Size | 65" diagonal, 16:9, ADS panel, direct LED |
| Resolution | 3840 x 2160 @ 60 Hz |
| Brightness | 750 cd/m² |
| Contrast | 1200:1 typical; 500,000:1 dynamic |
| Viewing Angle / Response | 178°/178°; 8 ms |
| Operating Hours | 24/7, landscape and portrait |
| Video Inputs | 3x HDMI 2.0, 1x DisplayPort 1.2, 1x DVI-I, 1x USB 2.0 |
| Video Outputs | 1x DisplayPort 1.2, 1x HDMI 2.0 |
| Other Connections | SDM-L slot, microSD, thermal sensor, ambient light sensor |
| Control | RJ45, RS232C in/out, IR in/out; loop-through on HDMI, DP, RS232, IR |
| Tiled Matrix | Up to 15 x 15 |
| Speakers | 2x 10W RMS |
| Power | 100–240 VAC; 155W typical, 330W max, <0.5W standby |
| Dimensions (W x H x D) | 57.71" x 32.96" x 3.54"; 61.3 lb |
| Bezel | 14.90 mm even bezel |
| Mounting | VESA 400 x 400 mm (M8); Smart Insert |
| MTBF | 50,000 hours |
| Approvals | ENERGY STAR 8.0, ETL, FCC Class A, CE, CB, EAC, VCCI, PSB, EPA |
| Warranty | 3 years |
| Included Accessories | Remote control, RS232 cable (3 m), RS232 daisy chain cable, power cables, wire clampers, quick start guide |
Frequently Asked Questions
Why choose a 750-nit display over a standard signage panel?
Higher brightness keeps content readable in window-facing retail, transit, and atrium installations where 350–500 nit panels appear washed out under ambient light.
Does this display have a built-in media player?
It plays media directly from USB, and the SDM-L slot accepts an Intel Smart Display Module for embedded compute without external cabling. It does not include an Android SoC like Philips D-Line models.
Can it be used in a video wall?
Yes. Tiled matrix support up to 15x15 with HDMI and DisplayPort loop-through allows multi-display arrays from a single source.
How does it integrate with AV control systems?
RS232C in/out, RJ45 LAN control, and IR loop-through support Crestron, Extron, AMX, and CMND & Control management across display fleets.
Is it suitable for portrait installation?
Yes. The display is rated 24/7 in both landscape and portrait orientations on a VESA 400x400 mount.
What warranty is provided?
Philips includes a 3-year commercial warranty. Creation Networks offers pre-sales assistance for brightness, mounting, and control-system planning.
