Philips 165BDL3105X/00 – X-Line 3x3 Video Wall Bundle (9x 55")

Product Overview

The Philips 165BDL3105X/00 is a complete Philips 3x3 video wall bundle built from nine X-Line 55BDL3105X commercial-grade displays, engineered for 24/7 operation in control rooms, lobbies, and retail environments. Each 55-inch video wall display delivers Full HD 1920 x 1080 resolution at 500 cd/m² brightness with an ultra-narrow 3.5 mm bezel-to-bezel profile for near-continuous imagery across the array. As a turnkey 24/7 commercial video wall solution, the bundle simplifies procurement for integrators specifying a nine-panel canvas in a single SKU. Built-in tiling mode and CMND & Control display management reduce the external hardware and software typically required for digital signage video wall installation.

Product Description

For commercial AV integrators, the 165BDL3105X/00 removes the guesswork from sourcing a matched nine-display array: every panel in this Philips 3x3 video wall ships from the same X-Line series with identical IPS direct-LED backlighting, Pure Colour Pro calibration, and 1.07 billion display colors for consistent color across all nine tiles. The 3.5 mm combined bezel (2.3 mm top/left, 1.2 mm bottom/right) keeps mullions visually minimal, which matters in broadcast studios and executive briefing centers where content frequently spans panels. Native tiling mode supports matrices up to 15 x 15 and distributes 4K content dot-by-dot across a 2x2 section without external video wall processors, lowering both rack space requirements and points of failure. IT and facilities teams manage the entire wall over LAN through CMND & Control or RS232/RJ45 with SICP, monitoring status and switching inputs for one screen or one hundred. FailOver automatically switches each display to a secondary input if the primary source drops, so a 24/7 commercial video wall never goes dark mid-shift. An OPS slot in each panel accepts a slot-in PC or the optional Android CRD50 module, eliminating external player cabling. DisplayPort and RS232 loop-through simplify daisy-chained signal distribution during digital signage video wall installation, and each display includes edge alignment kits, daisy-chain cables, and IR sensor cabling. Connectivity per panel covers HDMI (x2), DisplayPort, DVI-D, and VGA, with 400 x 400 mm VESA wall mounting and landscape or portrait placement. Each display is backed by a 3-year limited warranty and a 50,000-hour MTBF rating.

Browse the full Philips professional display collection at Creation Networks, or compare with the Philips 55BDL2105X/00 single video wall display for phased or smaller deployments.

Key Features

• Complete 3x3 Bundle (9 Displays) — One SKU delivers nine matched X-Line 55BDL3105X panels, ensuring uniform color, brightness, and bezel geometry across the entire wall.
• 24/7-Rated Commercial Operation — Designed for continuous duty in landscape or portrait with a 50,000-hour MTBF, suited to control rooms and always-on signage.
• Ultra-Narrow 3.5 mm Bezel-to-Bezel — A 2.3 mm + 1.2 mm bezel design keeps seams minimal so content reads as a single large canvas.
• 500 cd/m² Brightness with Pure Colour Pro — High luminance and advanced gamma calibration keep content legible in bright lobbies and daylight-facing spaces.
• Tiling Mode up to 15 x 15 — Native tiling distributes content, including 4K across a 2x2 section, without external video wall processors.
• CMND & Control Network Management — Operate, monitor, and maintain every panel over LAN (RJ45) or RS232 from a central console.
• FailOver Input Redundancy — Each display automatically switches to a secondary input if the primary source fails, keeping content on screen.
• OPS Slot for Embedded Compute — Slide in a full OPS PC or optional Android CRD50 module with no external cabling or media player shelf.
• Installer-Ready Accessory Kits — Each panel ships with edge alignment kits, RS232 daisy-chain cable, DVI-D and HDMI cables, and IR sensor cabling.

Typical Applications

• Boardroom
• Government space
• Commercial meeting space
• All-hands room
• Broadcast studio
• Auditorium
• House of worship

Technical Specifications

Frequently Asked Questions

Does this bundle require an external video wall processor?
No. Each 55BDL3105X includes native tiling mode supporting matrices up to 15 x 15, so a single source can be distributed across the 3x3 array via DisplayPort loop-through without an external processor. A processor remains an option for multi-window or multi-source layouts.

How is the wall managed after installation?
All nine displays are network controllable over LAN (RJ45) using CMND & Control, or via RS232 with the SICP protocol, allowing IT and facilities staff to monitor status, switch inputs, and schedule operation centrally.

Can it integrate with existing AV control systems?
Yes. RS232C in/out, RJ45, and IR in/out support integration with third-party control platforms, and RS232 daisy-chain cables are included with each display for serial control across the array.

What media player options does it support?
Each panel has an OPS slot that accepts a slot-in PC or the optional Philips CRD50 Android module, plus HDMI, DisplayPort, DVI-D, and VGA inputs for external players and signal extenders.

What warranty applies?
Philips backs each display with a 3-year limited commercial warranty. Contact Creation Networks for extended coverage and deployment support options.

Are mounts included?
Each display supports VESA 400 x 400 mm mounting and ships with edge alignment kits and alignment pins; video wall mounts are specified separately to match your wall structure and service-access requirements. Our team can quote a complete mount package.
